NT31-ST123-EV3


Part Number - NT31-ST123-EV3

NT31-ST123-EV3 is


Available


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the NT31-ST123-EV3
4.0/5 on 1 review


Product Details

  • NT Touchscreen Operator Interface (NT31ST123EV3)
  • Manufacturer: Omron
  • Series: NT

Product Description

The Omron NT31-ST123-EV3 (NT31ST123EV3) is a NT series operator interface with a touchscreen display. The touchscreen has an effective display area (height by width) of 118mm by 89mm (4.65in by 3.5in) wih a resolution of 320 x 240 dots. The screen has an enclosure rating of IP65 making it oil-proof and a great degree of resistance. This enclosure rating also denotes that the front panel is entirely protected against impinging dust and it is insulated from direct hits from low-pressure jets.

The NT31-ST123-EV3 can be connected to various links by a RS-232C, RS-422A, RS485 or a printer port. Some Omron NT link series which this touchscreen operator interface can be connected with are C200HX, C200HG, C200HE, and twenty others. It can also be connected with many host links and memory links from the Omron company. Some other links involve those of certain Mitsubishi series; some series were the FX series and the A series (computer link unit) like the FX1, FX2, and the AOJ2-C214S1 and many others. Lastly, some links that can be attached to the NT31-ST123-EV3 are from the Allen-Bradley, GE-Fanuc, and Siemens.

The NT31-ST123-EV3 touchscreen operator interface has a rayed power supply voltage of 24VDC. The permissible voltage range of this touchscreen is 20.4 to 26.4VDC. Its power consumption is 15W. The screens data capacity is 1MB. The ST123-EV3 interface has two serial ports for serial communications: A and B. Port A can append to an RS-232C cable. Port B can be appended to an RS-232C or RS-422A/485 (can be selected by memory switch setting) cable.

Here are the source material that may have been referenced:
https://www.mouser.com/datasheet/2/307/M11W111E1100406-16913.pdf
https://www.limasoft.cz/omron/pdf/c200h_hs.pdf
http://www.ia.omron.com/data_pdf/cat/nt_series_ds_e_2_6_csm2690.pdf


Technical Specifications

Part Number: NT31-ST123-EV3 (NT31ST123EV3)
Module Type: Touchscreen Operator Interface
Weight: 2.2lbs (1kg)
Panel Size: 118mm x 89mm
Pixels: 320 x 240


Related Parts

NT-DRT21 - Omron Communication Module


Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron NT Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron NT31-ST123-EV3 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.


Additional Information

TRW Electric & Supply Company is a global automation supplier. We deliver reliable new and refurbished parts at a great value. Our product focus is Omron and Mitsubishi products, but we have been able to provide our customers with solutions from other manufacturers as well. Our goal is to supply the automation industry with the best service and pricing, and of course conduct business with a high level of integrity.






Authorized Distributors

A Omron Authorized Distributor for NT is not the only source for Omron products. Many of the Omron products have been discontinued and therefore are no longer available from authorized suppliers. TRW Electric & Supply has many new and refurbished Omron NT parts available for purchase.


More Information: NT31 ST123 EV3, NT 31 ST123EV3, NT 31-ST123-EV3, NT31ST123-EV3
