CS1W-ETN21


Part Number - CS1W-ETN21

Product PDF: pdf image

CS1W-ETN21 is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the CS1W-ETN21
Be the 1st to rate this product listing!



Product Details

  • CS1 Control Module with Ethernet (CS1WETN21)
  • Manufacturer: Omron
  • Series: CS1

Product Description

The Omron CS1W-ETN21 (CS1WETN21) is a CS1 series control module with an Ethernet port. The ethernet port has a connector needed for the CS1W-ETN21’s port is one that follows RJ45 8-pin modular connector and conforms to the IEEE802.3 electrical specifications. This control module has three switches, the first one is unit number switch which set the unit number for this module and the other two switches are node address switches. These switches control the module’s FINS (Factory Interface Network Service) node number.

The CS1W-ETN21 control module uses the 100BASE-TX optimal for the Ethernet cable. This cable has a frequency of 100MHz and a baseband that allows the control module to use all the bandwidth that is accessible at the time. The control module has a communication span up to 100 meters. The wiring is an unshielded twisted pair (UTP). The 10 BASE-T cable can also be used. This wire permits the control module to communicate with other Omron configurations and personal computers that support a CX-Programmer, a CX-Integrator, SYSMAC Gateway, or Fins Gateway protocol in the Ethernet system’s hub. There are three industrial switching hubs the CS1W-ETN21 may connect with, and those are the W4S1-03B, the W4S1-05B, and the W4S1-05C. All of these have a current consumption of 0.22A.

The CS1W-ETN21 control module is compatible with two different systems, the CS1 and the CS1D system. However in both systems, this control module can only be placed on a CPU rack or an expansion backplane. In any case, it can only be with 4 other units per CPU.

Here is the source material that may have been referenced:
http://www.ia.omron.com/data_pdf/cat/cs1w-etn21_ds_e_5_4_csm2091.pdf?id=1680


Technical Specifications

Part Number: CS1W-ETN21 (CS1WETN21)
Module Type: Control Module
Ethernet Port
100BASE-TX, 10BASE-T
Weight: 0.44lbs (0.2kg)


Related Parts

C200H-DA003 - Omron C200H Control Module
CJ1W-OC211 - Omron CJ1 Control Module
CS1H-CPU63 - Omron CS1 Control Module (CS1HCPU63)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CS1 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron CS1W-ETN21 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
