CS1W-ETN11


Part Number - CS1W-ETN11

Product PDF: pdf image

CS1W-ETN11 is


Available


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the CS1W-ETN11
5.0/5 on 2 reviews


Product Details

  • CS1 Ethernet Control Module (CS1WETN11)
  • Manufacturer: Omron
  • Series: CS1

Product Description

The Omron CS1W-ETN11 (CS1WETN11) is a CS1 series control module with Ethernet communication. The control module is of the 10Base-T type wiring standard that sends 10 Mbps at a distance of almost 100 meter for every segment. This type of control module has a baseband modulation. The baseband indicates the for the Ethernet signal, only one will be in attendance for the sending and/or receiving pair. The CS1W-ETN11 10Base-T type also uses unshielded twisted-pair (UTP) cables, nevertheless these wires are insulated. One of the wires is for transmitting data while the other receives data.

The CS1W-ETN11 control module has three switches. The switch on top is a unit number switch that sets the communication control module’s unit number. The other two switches are node switches. These are used to set the module’s FINS (Factory Interface Network Service) node number. The FINS is one of Omron’s protocols. This protocol is used for data transfer and other such operations to distant PLCs that are connected to the Ethernet network of the CS1W-ETN11. Below the switches is the Ethernet connector which hooks the communication control module to an Ethernet transceiver cord.

The CS1W-ETN11 control module in the system configuration can work by carrying signals between nodes of integral multiples of 2.5 meters. The Ethernet control module connects with other Ethernet modules, linking groups of configurations together. They may also connect with a personal computer. Other connections made by the network may also be with computers with the CX-Programming device or with the controller link network by forming a connection with a CS series configuration.

Here is the source material that may have been referenced:
https://www.fa.omron.com.cn/data_pdf/mnu/w343-e1-07_cs1w_cj1w-etn.pdf?id=31


Technical Specifications

Part Number: CS1W-ETN11 (CS1WETN11)
Module Type: Control Module
Ethernet Communications
Type: 10Base-T
Weight: 0.66lbs (0.3kg)


Related Parts

CQM1-AD041 - CQM1 Analog Input Control Module (CQM1AD041)
CJ1M-CPU21 - Omron CJ1 Control Module (CJ1MCPU21)
R88D-WT20H - Omron R88D Servo Drive (R88DWT20H)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CS1 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron CS1W-ETN11 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
