CS1W-ETN01


Part Number - CS1W-ETN01

Product PDF: pdf image

CS1W-ETN01 is

In Stock Ships Today!In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the CS1W-ETN01
5.0/5 on 1 review



Product Details

  • CS1 Ethernet Control Module (CS1WETN01)
  • Manufacturer: Omron
  • Series: CS1

Product Description

The Omron CS1W-ETN01 (CS1WETN01) is a CS1 series control module with an Ethernet connector. This ethernet control module can be mounted to 1-4 units on a CPU rack or a CS1 expansion rack. The Ethernet connection can be made by a transceiver cable hooked to a transceiver and the 15-pin Ethernet connector. Below the Ethernet connector has two power supply screw terminals that can attach to an exterior 24VDC power supply for the transceiver. Then above the Ethernet connector of the CS1W-ETN01 there are three switches. The two immediately above the connector is the node number switch that sets this modules FINS node number. The switch above those is the unit number switch that sets the unit number of the Ethernet module.

The CS1W-ETN01 can communicate with other Ethernet devices by the UDP/IP and the TCP/IP protocols. And, as previously noted, the Ethernet communication control module is able to utilize FINS message communication. This allows the CS1W-ETN01 ethernet control module to access other PCs from Omron and can even allow access to the Controller Link and the Sysmac Link networks. This module also has the aptitude to send status and unit error information via email to PC. The CS1W-ETN01 control module also can connect to the controller link network connection by the FINS communication in order to permit monitoring of the module from a PC connected to the Ethernet.

The CS1W-ETN01’s dimension, length by width by height, is 130mm by 35mm by 116mm (if screw terminal cover is considered) or in English unit, 5.12in by 1.38in by 4.57in. Its weight is 0.66lbs (0.3kg).

Here is the source material that may have been referenced:
https://assets.omron.eu/downloads/datasheet/en/v2/r058_cs1w-etn01_ethernet_unit_datasheet_en.pdf
https://www.fa.omron.com.cn/data_pdf/mnu/w343-e1-07_cs1w_cj1w-etn.pdf?id=31


Technical Specifications

Part Number: CS1W-ETN01 (CS1WETN01)
Module Type: Ethernet Control Module
Ethernet Connector
Weight: 0.66lbs (0.3kg)


Related Parts

CS1W-AT011 - Omron CS1 Control Module (CS1WAT011)
CS1W-CLK11 - Omron CS1 Control Module (CS1WCLK11)
CJ1M-CPU21 - Omron CJ1 Control Module (CJ1MCPU21)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CS1 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron CS1W-ETN01 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
