CQM1H-CPU21
Product PDF:
CQM1H-CPU21 is
In Stock Ships Today!In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.com
Rate the CQM1H-CPU21
5.0/5 on 2 reviews
Product Details
- CQM1 Input Output Control Module (CQM1HCPU21)
- Manufacturer: Omron
- Series: CQM1
Product Description
The Omron CQM1H-CPU21 (CQM1HCPU21) is a CQM1 control module with input output points. The control module has a total input output capacity of 256 points, with the number of output points at 16 (DC). The CQM1H-CPU21 has a program capacity calculated by words is 3.2,000 words, while its DM capacity is 3,000 words. This control module does not support inner boards and controller link modules.On the right of the face of the CQM1H-CPU21 input output control module there is a peripheral port. This port connects the CPU to a programming device or personal computer; also, this port also supports a host link. A personal computer may be connected to the CPU21’s RS-232C port, which is directly below the peripheral port, as well.
The CQM1H-CPU21 can be the CPU control module for Omron’s flexible system configuration. Mounted on a DIN track (no mounting structure needed), the CPU control module can be linked via the integrated connectors, accompanied with sliders that allow the module to secure easily. End covers may also be furnished on either end of the configuration. Other units that may be joined to the CQM1H-CPU21 are as follows: a power supply unit, a controller unit, input output control modules, and dedicated input output control modules.
The CPU models of Omron have three different types of interrupts: Input interrupts, interval timer interrupts, and high speed counter interrupt. The input interrupt is carried out to react to input with an external genesis, this has a maximum of 4 inputs. The interval interrupt is a scheduled interruption demarcated by an internal timer, this interruption has a maximum of 3 timers. The high-speed counter interrupts which interrupts based on two types of comparisons: target value comparison and range comparison.
Here are the source material that may have been referenced:
https://media.digikey.com/pdf/Data%20Sheets/Omron%20PDFs/CQM1H.pdf
http://cqm1.ru/techdocs/cqm1h-cpu-datasheet.pdf
Technical Specifications
Part Number: CQM1H-CPU21 (CQM1HCPU21)Module Type: Control Module
Number of Input Output points: 16 (DC)
Weight: 1 lb (Approx.)
Related Parts
CJ1M-CPU12 - Omron CJ1 Programmable Control Module (CJ1MCPU12)R88D-WT20H - Omron R88D Servo Drive (R88DWT20H)
R88D-WT15H - Omron R88D Servo Drive (R88DWT15H)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Omron CQM1 Shipping options vary by location. Call for an accurate quote.
Warranty
- The Omron CQM1H-CPU21 comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
Additional Information
TRW Electric & Supply Company is a global automation supplier. We deliver reliable new and refurbished parts at a great value. Our product focus is Omron and Mitsubishi products, but we have been able to provide our customers with solutions from other manufacturers as well. Our goal is to supply the automation industry with the best service and pricing, and of course conduct business with a high level of integrity.
Authorized Distributors
A Omron Authorized Distributor for CQM1 is not the only source for Omron products. Many of the Omron products have been discontinued and therefore are no longer available from authorized suppliers. TRW Electric & Supply has many new and refurbished Omron CQM1 parts available for purchase.
