CQM1H-CPU11


Part Number - CQM1H-CPU11

Product PDF: pdf image

CQM1H-CPU11 is

In Stock Ships Today!In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the CQM1H-CPU11
3.4/5 on 5 reviews



Product Details

  • CQM1 Input Control Module (CQM1HCPU11)
  • Manufacturer: Omron
  • Series: CQM1

Product Description

The Omron CQM1H-CPU11 (CQM1HCPU11) CQM1 Input Control Module is a programmable CPU module. The control module has a program capacity of 3.2K words and a DM capacity of 3K words.

Programmable Control Module CPUs are split into two brackets, there are those which are capable of supporting inner boards and a Controller Link Unit and those that are not able. This particular CPU does not support the aforesaid. The CQM1H-CPU11 has a mini-peripheral port that connects to programming mechanism like programming consoles or a PC that runs the CX-programmer. This CPU, unlike its other three CQMIH counter parts, does not have an integrated RS-232C. In an Omron configuration, the CPU will be placed between a power supply (since it does not support a control link module) and a host of specialized input output control modules. The CQM1H-CPU11 is supplied with connectors positioned on either side of the module so it can hitch to other units with an Omron configuration and sliders to secure the connection.

The CQM1H-CPU11 has three types of interrupts: the input interrupts, the interval timer, and the high-speed counter interrupt. The input interrupt is a reaction when external sources offer input on top of the input points already integrated into the CQM1H-CPU11. The interval timer interrupt is an interruption that happens at regular interims. And lastly, the high-speed counter interrupt is an interrupt with two comparisons: the target value and range. The target comparison is an interrupt performed when the counter PV is commensurate with the specified value the range comparison is performed when the counter PV is within a specific range.

Here are the source material that may have been referenced:
https://media.digikey.com/pdf/Data%20Sheets/Omron%20PDFs/CQM1H.pdf;
http://cqm1.ru/techdocs/cqm1h-cpu-datasheet.pdf


Technical Specifications

Module Type: CQM1H-CPU11 Input Control Module
Number of Input Output points: 256
Weight: 1 lb. (Approx.)


Related Parts

CQM1-IA121 - Omron CQM1 Input Control Module
CQM1-ID211 - Omron CQM1 Input Control Module
CQM1-IPS02 - Omron Sysmac PLC POWER SUPPLY Control Module



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CQM1 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron CQM1H-CPU11 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
