CQM1-TC002
Product PDF:
CQM1-TC002 is
In Stock Ships Today!In Stock Ships Today!In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.com
Rate the CQM1-TC002
5.0/5 on 3 reviews
Product Details
- CQM1 Input Temperature Control Module (CQM1TC002)
- Manufacturer: Omron
- Series: CQM1
Product Description
The Omron CQM1-TC002 (CQM1TC002) is a CQM1 series control module with a input temperature (thermocouple) sensor. The control modules input temperature sensor types are ‘K’ and ‘J’. The ‘K’ type controls temps between the set point ranges of -300 to 2,300°F (200 to 1,300°C); while the ‘J’ type sets temperatures between -100 to 1,500°F (100 to 850°C). This control module also has 2 control loops, but only on needs to be used. The CQM1-TC002’s internal current consumption is, when the voltage is at 5VDC is 220mA and the modules external supply voltage is 15mA per minute with a voltage of 24VDC with +10% and -15%.The parameters can be placed by handing down commands from the PLC. Commands for this module are conducted by the transfer I/O command instruction which is part of a CQM1H CPU module. The PID (Proportional Integral Derivative) indemnifies a stable temperature control for the CQM1-TC002 temperature control module.
The CQM1-TC002 control module is of the sourcing output type. The sourcing output has a PNP (positive-negative-positive) transistor which sources positive power to the output. The PNP transistor outputs with short-circuit safeguard. In an Omron configuration, the temperature module will be one of the specialized I/O modules which manage the thermocouple. In the configuration, the CQM1-TC002 control module can also be placed next to a counterpart module, the CQM1-TC10[]/30[] which controls a platinum resistance thermometer. The module can be connected to the latter mentioned module and any other specialized input or output module with connectors incorporated in the side of the module.
Here is the source material that may have been referenced:
https://www.farnell.com/datasheets/1699916.pdf
Technical Specifications
Part Number: CQM1-TC002 (CQM1TC002)Module Type: Control Module
Input Temperature (Thermocouple) Sensor
Output Voltage: 24VDC
Weight: 1lb (Approx.)
Related Parts
CQM1-IA121 - Omron CQM1 Control ModuleCJ1M-CPU12 - Omron CJ1 Programmable Control Module (CJ1MCPU12)
R88D-WT15H - Omron R88D Servo Drive (R88DWT15H)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Omron CQM1 Shipping options vary by location. Call for an accurate quote.
Warranty
- The Omron CQM1-TC002 comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
Additional Information
TRW Electric & Supply Company is a global automation supplier. We deliver reliable new and refurbished parts at a great value. Our product focus is Omron and Mitsubishi products, but we have been able to provide our customers with solutions from other manufacturers as well. Our goal is to supply the automation industry with the best service and pricing, and of course conduct business with a high level of integrity.
Authorized Distributors
A Omron Authorized Distributor for CQM1 is not the only source for Omron products. Many of the Omron products have been discontinued and therefore are no longer available from authorized suppliers. TRW Electric & Supply has many new and refurbished Omron CQM1 parts available for purchase.
