CQM1-OD216
Product PDF:
CQM1-OD216 is
In Stock Ships Today!In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.com
Rate the CQM1-OD216
4.7/5 on 3 reviews
Product Details
- CQM1 Output Control Module (CQM1OD216)
- Manufacturer: Omron
- Series: CQM1
Product Description
The Omron CQM1-OD216 (CQM1OD216) is a CQM1 series output control module with 32 points. The control module is not permitting to use a screw terminal since the module itself is too small instead, a PNP transistor is used. There are forty pins which can be classified with the appellations A1-A20 and B1-B20. Pins A1-A8, A11-A18, B1-B8, and B11-B18 are all individual outputs. All output points participate in one circuit. Pins A9, A19, B9, and B19 are 0V terminals and pins A10, A20, B10, and B20 are COM terminals. It is to be noted that even though the 0V and COM terminals are internally connected, they still must be wired.The CQM1-OD216 control module has a maximum switching capacity of 0.5 Amp when it at 24VDC +10%/-15%. The leakage current is 0.1 Amp and the residual voltage is 0.8V. The module’s internal current consumption is 240mA at 5VDC. The service power supply must be at least 160mA because ever ON point generates 5mA (there are 32 points) at 24VDC +10%/-15%. Finally, the ON delay for starting the CQM1-OD216 is 0.1ms while the OFF delay is 0.3ms.
In an Omron configuration, beside the power supply should be a CPU; next to the CPU can be any specialized input or output control module such as the CQM1-OD216. The output control module makes its connection to fellow control module by the use of its connectors which is subsumed on the side of the modules. These connections then can be safely secure by the sliders residing on the top and bottom of the control module.
Here is the source material that may have been referenced:
https://www.farnell.com/datasheets/1699916.pdf
Technical Specifications
Part Number: CQM1-OD216 (CQM1OD216)Module Type: Control Module
Number of Transistor Output Points: 32
Weight: 0.46lbs (0.21kg)
Related Parts
CJ1M-CPU12 - Omron CJ1 Programmable Control Module (CJ1MCPU12)CJ1M-CPU13 - Omron CJ1 Control Module (CJ1MCPU13)
CJ1M-CPU21 - Omron CJ1 Control Module (CJ1MCPU21)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Omron CQM1 Shipping options vary by location. Call for an accurate quote.
Warranty
- The Omron CQM1-OD216 comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
