CJ2M-CPU12


Part Number - CJ2M-CPU12

Product PDF: pdf image

CJ2M-CPU12 is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the CJ2M-CPU12
4.3/5 on 3 reviews



Product Details

  • CJ2 Input Output Control Module (CJ2MCPU12)
  • Manufacturer: Omron
  • Series: CJ2

Product Description

The Omron CJ2M-CPU12 (CJ2MCPU12) is a CJ2 series control module with input output points. The control module has a data capacity of 160,000 words which are divided between its data memory (DM) of 32,000 words and an extended memory (EM) of 32,000 words x 1 bank. The program capacity of the CJ2M-CPU12 control module is 10,000 steps. The input and output capacity is 2,560 points for every 40 units with three expansion racks. The current consumption of the module is 0.5 AMP when the voltage is 5V.

The CJ2M-CPU12 control module has two ports a peripheral port and a serial port. The peripheral connects to programming mechanism like the CX-programmer with the use of the USB. The baud rate of the port is 12Mbps with a transmission distance of 5 meters. The serial connects to programming mechanism, host computers, and many other devices. The serial conforms to the EIA RS-232C adapter. The baud rate of this port is 0.3, 0.6, 1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6, and 115.2 kbps with a transmission distance of 15 meters. The memory card for the CJ2M-CPU12 control module with block memory may be placed into the memory card connector which resides right next to the two ports. There is also a battery compartment which can afford to carry a CJ1W-BAT01 battery.

In the Omron configuration the CJ2M-CPU12 is the main control module. A power supply module must be placed next to the CPU with a PFP-M end plate. The other modules it may connect to may be other specialized input or output control modules.

Here are the source material that may have been referenced:
https://assets.omron.eu/downloads/manual/en/v4/w472_cj2_cpu_units_hardware_users_manual_en.pdf


Technical Specifications

Part Number: CJ2M-CPU12 (CJ2MCPU12)
Module Type: Control Module
Block Memory
Input Output Points: 2,560
Weight: 0.29lbs. (0.13kg)


Related Parts

CJ1W-ID211Q - Omron INPUT OUTPUT (CJ1WID211Q)
CJ1W-ID262 - Omron CJ1 Control Module (CJ1WID262)
CQM1-OC222 - Omron CQM1 Output Control Module (CQM1OC222)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CJ2 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron CJ2M-CPU12 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
