CPM1A-20CDR-A-V1
CPM1A-20CDR-A-V1 is
In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.comProduct Details
- CPM1 Programmable Control Module (CPM1A20CDRAV1)
- Manufacturer: Omron
- Series: CPM1
Product Description
The Omron CPM1A-20CDR-A-V1 (CPM1A20CDRAV1) is a relay output programmable controller of the CPM1. CPM1 controllers are able to be easily constructed within variegated machines and control panels due to its compact size.The CPM1A-20CDR-A-V1 may have or be used as an expansion unit, linked by a connecting cable. It also has a peripheral port that may connect to either the CPM1-CIF01 (RS-232C interface) or CPM1-CIF11 (RS-422 interface) adapter. This unit may have up to 3 expansions. Expansion units may be as follows: expansion I/O units, analog I/O units, CompoBus I/O link units, DeviceNet I/O link units, and a CPM1A-TS001/101 module. Other connections permitted by the relay output programming module can be a Window-based CX-programmer, requiring the CQM1-CIF02 peripheral connecting cable. It also has a peripheral port that may connect to either the CPM1-CIF01 (RS-232C interface) or CPM1-CIF11 (RS-422 interface) adapter. The other possible connection is with a programming console (such as the CQM1-PRO01 or a C200H-PRO27-E), made by C200H-CN222/CN422 programming console connecting cable.
The CPM1A-20CDR-A-V1 has a power supply voltage of 100-240VAC and a frequency of 50/60Hz. Its power consumption is 30VA max. while its inrush current is 30A max. The CPM1A-20CDR-A-V1 controller has 8 output points and 12 (DC) input points, making the total number of I/O of 20 points. Even though the CPM1A-20CDR-A-V1 is a compact unit, it can handle very intricate operations; this is shown by its user memory of 2,048 words and data memory of 1,024 words. This controller, as a member of the CPM1A series, has a high-speed execution. The LOAD instructions are accomplished in 1.7 µs and its MOVE instruction are consummated in 16.3µs.
Here is the source material that may have been referenced:
http://pdf2.datasheet.su/omron%20automation/cpm1a-20cdr-a-v1.pdf
Technical Specifications
Module Type: Programmable Controller CPM1A-20CDR-A-V1Voltage/Frequency: 100-240VAC, 50/60Hz
Number of Outputs: 8pt
Number of Inputs: 12pt (DC)
Weight: 1.1lbs (0.5kg)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Omron CPM1 Shipping options vary by location. Call for an accurate quote.
Warranty
- The Omron CPM1A-20CDR-A-V1 comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
