CJ2M-CPU35


Part Number - CJ2M-CPU35

Product PDF: pdf image

CJ2M-CPU35 is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the CJ2M-CPU35
4.8/5 on 5 reviews



Product Details

  • CJ2 Input Output Control Module (CJ2MCPU35)
  • Manufacturer: Omron
  • Series: CJ2

Product Description

The Omron CJ2M-CPU35 (CJ2MCPU35) is a CJ2 series input output control module with 2,560 points. The control module has a program capacity of 60,000 steps and a data memory capacity of 160,000 words. There can be 40 mountable control modules on at most 3 racks for every 2,560 points. The data memory capacity is able to be split into 32K words of data memory and 32K words times 4 banks for its extended memory. The current consumption of the CJ2M-CPU35 control module is at 5V, 700mA.

Integrated into the CJ2M-CPU35 input output control module are two ports along with an option board slot. The two ports are the peripheral that connects with programming devices and an EtherNet/IP which appends to an information management system. The peripheral port of the CJ2M-CPU35 utilizes the peripheral bus with a USB interface. This interface’s baud rate is 12Mbps and its transmission distance is 5 meters. The EtherNet/IP port deploys a 100Base-TX cable which is a shielded twisted-pair cable whose baud rate is 100Mbps, linking it to a switching hub. In the option board slot can hold one of three option cards: the CP1W-CIF01 (RS-232C), the CP1W-CIF11 (RS-422A/485), and the CP1W-CIF12 (isolated-type RS422A/485).

When participating in an Omron configuration the CJ2 control module needs to connect to a power supply and can also link with other specialized and dedicated input and output modules. Connections are confirmed when a linkage happens with the incorporated connectors attach and are secured by the sliders which are placed on many Omron modules.

Here are the source material that may have been referenced:
https://assets.omron.eu/downloads/manual/en/v4/w472_cj2_cpu_units_hardware_users_manual_en.pdf


Technical Specifications

Part Number: CJ2M-CPU35 (CJ2MCPU35)
Module Type: Input Output Control Module
EtherNet/IP - Information Management System
Number of Input Output Points: 2,560
Weight: 0.42lbs. (0.19kg)


Related Parts

CJ1W-ID211Q - Omron Input Output Module (CJ1WID211Q)
CJ1W-ID262 - Omron CJ1 Control Module (CJ1WID262)
CQM1-OC222 - Omron CQM1 Output Control Module (CQM1OC222)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CJ2 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron CJ2M-CPU35 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
