CJ2M-CPU34


Part Number - CJ2M-CPU34

Product PDF: pdf image

CJ2M-CPU34 is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the CJ2M-CPU34
5.0/5 on 1 review



Product Details

  • CJ2 Input Output Control Module (CJ2MCPU34)
  • Manufacturer: Omron
  • Series: CJ2

Product Description

The CJ2M-CPU34 (CJ2MCPU34) is a CJ2 series input output control module. This control module can have up to 3 expansions with its input output capacity of 2,560 points per 40 units. The CJ2 control module possesses a program capacity of 30K and current consumption of 0.7 Amp when the voltage is at 5V. The data memory capacity, which is 160K words is ramified into 32K words for the data memory (DM) and 32K words times 4 banks for the extended memory (EM).

The CJ2M-CPU34 input output control module has not only two ports, but also an option board slot. The option board slot is conformable to either one of the two individual serial option boards or an isolated-type option board. The first one is the CP1W-CIF01 RS-232C board; the other is the CP1W-CIF11 RS-422A/485 option board; the last one, the isolated-type, is the CP1W-CIF12 RS-455A/485. The two ports in the CJ2M-CPU34 CJ2 control module is a peripheral port and the EtherNet/IP port. The first port can connect with programming device like a CX-programmer. The second port affords a connection with the Ethernet system with a 100Base-TX cable. Such a cable’s baud rate is 100Mbps whose transmission distance is 100 meters running through a shielded twisted-pair (STP) cable.

The CJ2M-CPU34 control module has two types of instructions: basic and special. Basic instructions are executed within 0.04µs and special instructions of 0.06µs. Added to this are two types of tasks, the cyclic and interrupt. There are 128 cyclic tasks and 256 interrupt tasks; however all the interrupt tasks may become an extra cyclic task.

Here are the source material that may have been referenced:
https://assets.omron.eu/downloads/manual/en/v4/w472_cj2_cpu_units_hardware_users_manual_en.pdf


Technical Specifications

Part Number: CJ2M-CPU34 (CJ2MCPU34)
Module Type: Input Output Control Module
Peripheral and EtherNet/IP Port
Input Output Capacity: 2,560 points
Weight: 0.42lbs. (0.19kg)


Related Parts

CP1W-CIF12 - Omron RS422/485 500M LONG RANGE (CP1WCIF12)
CJ2M-CPU15 - Omron CJ2 Control Module (CJ2MCPU15)
CP1W-TS101 - Omron CP1 Expansion Control Module (CP1WTS101)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CJ2 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron CJ2M-CPU34 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
