CJ2M-CPU15
Product PDF:
CJ2M-CPU15 is
In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.com
Rate the CJ2M-CPU15
5.0/5 on 2 reviews
Product Details
- CJ2 Input Output Control Module (CJ2MCPU15)
- Manufacturer: Omron
- Series: CJ2
Product Description
The CJ2M-CPU15 (CJ2MCPU15) is a CJ2 series input output control module with 2,560 points. This control module has an input output capacity of 2,560 points for every 40 units the CPU can have up to 3 expansion racks. The program capacity of this control module is 60,000 steps and a data memory capacity of 160,000 words. The data memory capacity can be bifurcated between a data memory (DM) of 32,000 words and an extended memory of 32,000 words times 4 banks. Lastly, the module’s current consumption is 500mA when the voltage is at 5V.There are two types of tasks in the CJ2M-CPU15: the cyclic and the interrupt. There are 128 proper cyclic tasks, yet every interrupt tasks can also count as an extra cyclic task. Then, there are 256 interrupt tasks divided between four other types of interrupt tasks. The scheduled interrupt are done at specific intervals. Power OFF interrupts occur when the CJ2M-CPU15 is turned OFF. The input output control module interrupt can happen when the input signal is fed to an interrupt module. External interrupts are executed when they are solicited by other control modules or a CPU bus module.
The CJ2M-CPU15 control module has a memory cad connector which links a memory card to the CPU. Besides this connector are two ports. The first port is the peripheral (USB) port. The peripheral port connects to a programming device like a CX-Programmer. This port has a baud rate of 12Mbps and a transmission distance of 5 meters. The peripheral port also uses the peripheral bus protocol. The other port within the CJ2M-CPU15 is a built-in serial port that conforms to an EIA RA-232C interface.
Here are the source material that may have been referenced:
https://assets.omron.eu/downloads/manual/en/v4/w472_cj2_cpu_units_hardware_users_manual_en.pdf
Technical Specifications
Part Number: CJ2M-CPU15 (CJ2MCPU15)Module Type: Input Output Control Module
Input Output Capacity Points: 2,560
Current Consumption: 500mA = voltage 5V Weight: 0.29lbs. (0.13kg)
Related Parts
CJ2M-CPU14 - Omron CJ2 Control Module (CJ2MCPU14)CJ1M-CPU12 - Omron CJ1 Programmable Control Module (CJ1MCPU12)
CJ1M-CPU13 - Omron CJ1 Control Module (CJ1MCPU13)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Omron CJ2 Shipping options vary by location. Call for an accurate quote.
Warranty
- The Omron CJ2M-CPU15 comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
