CJ2M-CPU13

Product PDF:

CJ2M-CPU13 is

In Stock Ships Today!In Stock Ships Today!

Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com

Rate the CJ2M-CPU13

4.0/5 on 1 review

Product Details

CJ2 Input Output Control Module (CJ2MCPU13)
Manufacturer: Omron
Series: CJ2

Product Description

The Omron CJ2M-CPU13 (CJ2MCPU13) is a CJ2 series control module with input output points. This control module has an capacity of 2,560 input output points for every 40 units and can only have up to 3 expansion racks. The data memory capacity is 160k words that are divided between the data memory (DM) of 32k words and the extended memory (EM) of 32k words times a bank. The program capacity is 20k steps. The CJ2M-CPU13’s current consumption is 500mA at 5V but can be increased depending on the adapter(s) used.

There are two ports on the CJ2M-CPU13 input output control module. The first one is a peripheral (USB) port that links with programming devices like a CX-Programmer. This port uses the peripheral bus protocol and has a baud rate of 12Mbps. The interface used is a USB 2.0-compliant B-type connector. Then, there is the built-in serial port which can also connect with a host of programming devices and can use many protocols such as the peripheral bus, host link, and other. The baud rate can go from 0.3 to 115.2kbps, but even though the CJ2M-CPU13 can support the high baud rates of 38.4 to 115.2kbps, not all computers are able to handle it, so the baud rate must be lowered.

The Omron CJ2M-CPU13 control module needs to attach itself to a power supply or a control module that has an integrated power supply. Connections can be made by the linkage of the connectors placed on the side of the control module.

Here are the source material that may have been referenced:
https://assets.omron.eu/downloads/manual/en/v4/w472_cj2_cpu_units_hardware_users_manual_en.pdf

Technical Specifications

Part Number: CJ2M-CPU13 (CJ2MCPU13)
Module Type: Control Module
Number of Input Output Points: 2,560
Weight: 0.29lbs. (0.13kg)

Related Parts

CJ2M-CPU33 - Omron CJ2 Control Module
CJ2M-CPU32 - Omron CJ2 Control Module
C200H-AD003 - Omron C200H Control Module

Shipping and Order Information

TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
Omron CJ2 Shipping options vary by location. Call for an accurate quote.

Warranty

The Omron CJ2M-CPU13 comes with a two year warranty.
A three year warranty is available. Please inquire for pricing.
