CJ2H-CPU66-EIP


Part Number - CJ2H-CPU66-EIP

Product PDF: pdf image

CJ2H-CPU66-EIP is


Available


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the CJ2H-CPU66-EIP
5.0/5 on 1 review


Product Details

  • CJ2 Input Output Control Module with EtherNet/IP (CJ2HCPU66EIP)
  • Manufacturer: Omron
  • Series: CJ2

Product Description

The Omron CJ2H-CPU66-EIP (CJ2HCPU66EIP) is a CJ2 series input output control module with EtherNet/IP points. This input output control module has an capacity of 2,560 points for every 40 units, permitting up to 3 expansion racks. Its program capacity is 100K steps while it data memory capacity is 160K words divided into 32K words of data memory (DM) and 32K words times 4 banks of extended memory (EM). The current consumption for the CJ2H-CPU66-EIP, when it is at 5V is 0.82 Amp and 0 Amp when it is at 24V. It may be an escalation in amperes added that depends on the adapter used.

The CJ2H-CPU66-EIP input output control module with EtherNet/IP has three distinct interfaces: the peripheral (USB) interface, the serial interface and the EtherNet/IP interface. The peripheral interface will connect with programming devices like a CX-Programmer. The serial interface links with host computers, programmable terminals and many other devices. The EtherNet/IP interface attaches to an information management system, i.e. a host computer. Beside the peripheral and serial interface is the memory card compartment. This compartment connects the memory card to the CJ2H-CPU66-EIP CPU module. For the safe removal of the memory card from the CPU, the module possesses a power supply switch which turns off the power permitting for a secure disconnect. There is also a battery compartment which supports the CJ1W-BAT01 battery.

In a classic Omron configuration the CJ2H-CPU66-EIP control module with EtherNet/IP is the CPU that would be connected to the power supply and to a number of specialized input and output modules by the unit connectors on the side of the module. The configuration can then be secured by the sliders.

Here are the source material that may have been referenced:
https://assets.omron.eu/downloads/datasheet/en/v2/cj2h-cpu6_-eip_cpu_units_with_built-in_ethernet_ip_datasheet_en.pdf


Technical Specifications

Part Number: CJ2H-CPU66-EIP (CJ2HCPU66EIP)
Module Type: Input Output Control Module with EtherNet/IP
EtherNet Input Output Points: 2,560
Weight: 0.62lbs (0.28kg)


Related Parts

CJ1M-CPU12 - Omron CJ1 Programmable Control Module (CJ1MCPU12)
CJ1M-CPU13 - Omron CJ1 Control Module (CJ1MCPU13)
CQM1-OC222 - CQM1 Output Control Module (CQM1OC222)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CJ2 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron CJ2H-CPU66-EIP comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
