CJ2H-CPU65-EIP

Product PDF:

CJ2H-CPU65-EIP is

Available

Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com

Rate the CJ2H-CPU65-EIP

5.0/5 on 1 review

Product Details

CJ2 Input Output Control Module (CJ2HCPU65EIP)
Manufacturer: Omron
Series: CJ2

Product Description

The Omron CJ2H-CPU65-EIP (CJ2HCPU65EIP) is a CJ2 series input output control module with EtherNet IP points. This control module has a user memory of 50,000 steps and its number of input output points is 2,560. The program capacity 100,000 steps while the data memory capacity is 160,000 words which is divided into data memory(DM) of 32,000 and extended memory (EM) of 32,000 word and 4 banks.

The CJ2H-CPU65-EIP control module can be connected to up to 10 units as the maximum is it is hitched to either a CPU rack or an expansion rack. However, the total number of PLCs that it can hitch with is 40 modules maximum. The CJ2H-CPU65-EIP module also utilizes the CJ1W-BAT01 battery that is put into the battery compartment. Since the communication control is an Omron product, it is rightly joined to an Omron configuration. In this configuration, the positioning of the CPU is placed between I/O units and a power supply. Since it is neither a power supply nor an external I/O, end covers are unnecessary for this particular module.

The CJ2H-CPU65-EIP input output control module has three ports with different functions. The first port is the EtherNet IP, allowing the CPU to connect with a host computer so that the computer may control and manage the EtherNet Network. Then, there is the serial port which is used to connect to programming devices (which may include a host computer) and other external mechanisms via an adapter. The peripheral port of the CJ2H-CPU65-EIP employs a USB cable to likewise connect with a programming device i.e. the CX-programmer.

Here are the source material that may have been referenced:
https://assets.omron.eu/downloads/datasheet/en/v2/cj2h-cpu6_-eip_cpu_units_with_built-in_ethernet_ip_datasheet_en.pdf

Technical Specifications

Part Number: CJ2H-CPU65-EIP (CJ2HCPU65EIP)
Module Type: Input Output Control Module
Number of Input Output Points: 2,560
Weight: 0.617lbs (0.280kg)

Related Parts

CJ1M-CPU21 - Omron CJ1 Control Module (CJ1MCPU21)
CQM1-CPU21 - CQM1 Control Module (CQM1CPU21)
CQM1-OC222 - CQM1 Output Control Module (CQM1OC222)

Shipping and Order Information

TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
Omron CJ2 Shipping options vary by location. Call for an accurate quote.

Warranty

The Omron CJ2H-CPU65-EIP comes with a two year warranty.
A three year warranty is available. Please inquire for pricing.
