CS1W-ID291

Product PDF:

CS1W-ID291 is

In Stock Ships Today!

Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com

Rate the CS1W-ID291

5.0/5 on 2 reviews

Product Details

CS1 Input Control Module (CS1WID291)
Manufacturer: Omron
Series: CS1

Product Description

The Omron CS1W-ID291 (CS1W-ID291) is a CS1 series input control module with 96 points. The CS1W-ID291 control module has an input voltage of 24VDC and a current of approximately 5m Amp. The ID291 has 96 points which is divided between the CN1 and CN2 connectors. Both Connectors have pins named A1-A28 and B1-B28. For both connectors, pins A1-A8, B1-B8, A10-A17, B10-B17, A19-A26, and B19-B26 all receive individual input. Pins A9, A18, and A27 for both connectors are COM terminals. Pins B9, B18, B27-B28, and A28 are terminals with no connections (NC), and this is also true for both connectors. Not only that, but both connectors of the CS1W-ID291 have three circuits, and all have an input voltage of 24VDC as previously mentioned.

The CS1W-ID291 input control module can be mounted on different racks such as the CPU rack, CS1 expansion rack, and CS1 long-distance racks. There are no connectors or sliders placed on the module. Therefore it requires some sort of expansion rack or backplane. These modules can connect to the expansion rack or backplane by a hook and connector which are on the back side of all these modules. In an Omron configuration, this input module may be placed as a specialized input output module alongside another specialized input output module or serial communication module with a CPU unit and a power supply. By having the CS1W-ID291 control module in the Omron configuration, it can now operate as an input module for the system. The CS1 system can connect to a host computer, keypad, programming console, and many other devices.

Here is the source material that may have been referenced:
https://www.digchip.com/datasheets/parts/datasheet/1726/CS1W-ID291-pdf.php

Technical Specifications

Part Number: CS1W-ID291 (CS1WID291)
Module Type: Control Module
Number of Input Points: 96
Weight: 1lb (Approx.)

Related Parts

CJ1M-CPU12 - Omron CJ1 Programmable Control Module (CJ1MCPU12)
CQM1-OC222 - CQM1 Output Control Module (CQM1OC222)
R88D-WT15H - Omron R88D Servo Drive (R88DWT15H)

Shipping and Order Information

TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
Omron CS1 Shipping options vary by location. Call for an accurate quote.

Warranty

The Omron CS1W-ID291 comes with a two year warranty.
A three year warranty is available. Please inquire for pricing.
