CJ1W-TC001

Product PDF:

CJ1W-TC001 is

In Stock Ships Today!In Stock Ships Today!

Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com

Rate the CJ1W-TC001

5.0/5 on 1 review

Product Details

CJ1 Temperature Control Module (CJ1WTC001)
Manufacturer: Omron
Series: CJ1

Product Description

The Omron CJ1W-TC001 (CJ1WTC001) is a CJ1 series temperature control module. The control module has input and output thermocouple sensors, input types R, S, K, J, T, L, and B. The temperature range for each type of input is 0 to 1,700 degrees Celsius for ‘R’ and ‘S’, -200 to 1,300 degrees Celsius for ‘K’, -100 to 850 degrees Celsius for ‘J’ and ‘L’, -200 to 400 degrees Celsius for ‘T’ and 100 to 1,800 degrees Celsius for 'B'.

There are three status indicators on the side of the top of CJ1W-TC001 temperature control module. The first is the ‘RUN’ indicator which is lit green when operations are normal; the second is signified by the appellation ‘ERC’ an is lit red when there is an error in the control module; the third is the ‘ERH’ which is also lit red denoting an error in the CPU. Next to that are output indicators and below that is a DIP switch. There is also an input type switch on the CJ1W-TC001 control module. Lastly there is a 4 loop, NPN (negative-positive-negative) terminal block with 18 screw terminals. From these terminals ensues four input points (a total of eight terminals used), four output points, two cold-junction comp., two N.C. terminals, and the 0V and 24V terminals.

Only the CJ system is capable of supporting the CJ1W-TC001 temperature control module. It can be placed on either the CPU rack or an expansion backplane from the CJ system and either rack or backplane can have 10 modules (the expansion backplane may have 10 units per expansion).

Here are the source material that may have been referenced:
https://www.ia.omron.com/data_pdf/cat/cj1w-tc_ds_csm1622.pdf?id=1438

Technical Specifications

Part Number: CJ1W-TC001 (CJ1WTC001)
Module Type: Temperature Control Module
Number of Input Output points: 8
Weight: 0.33lbs (0.15kg)

Related Parts

CJ1W-TC002 - Omron CJ1 Control Module
CJ1W-TC103 - Omron CJ1 THERMOMETER Module
CJ1W-SRM21 - Omron CJ1 Control Module SRM 21

Shipping and Order Information

TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
Omron CJ1 Shipping options vary by location. Call for an accurate quote.

Warranty

The Omron CJ1W-TC001 comes with a two year warranty.
A three year warranty is available. Please inquire for pricing.
