CJ1W-SRM21
Product PDF:
CJ1W-SRM21 is
In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.com
Rate the CJ1W-SRM21
5.0/5 on 1 review
Product Details
- CJ1 Input Output Control Module (CJ1WSRM21)
- Manufacturer: Omron
- Series: CJ1
Product Description
The Omron CJ1W-SRM21 (CJ1WSRM21) is a CJ1 series input output control module with a CompoBus/S master port. This input output control module can have up to 32 attachable units in the system. There is a horde of modules that can be connected, such as remote input terminals, remote output terminals, sensor terminals, analog input terminals, analog output terminals and so on. The CJ1W-SRM21 can have 40 mountable master units for every CPU control module.The CJ1W-SRM21 control module can have 128 input and output points at most and within its 64 in points and 64 out points, the master control module can have 256 in or out points with 128 inputs and 128 outputs. Either the 128 points or the 256 points can be chosen by a switch. The current consumption is 150mA when the voltage is at 5V. The communication cycle time is 0.5ms at 750kbps and the communication distance can stretch to 500 meters.
The CJ1W-SRM21 control module has two rotary switches that are utilized to set the special input output number. The top switch sets the ten’s digit and the bottom one sets the one’s. There is also a DIP switch with four pins. The first pin’s function is setting the usable node number, the second one starts the communication mode and the third one stops it, the fourth pin is a registration function. The CJ1W-SRM21 input output control module with CompoBus/S master has a communication connector that concatenates the communication power supply by the communication cables. The control module is not being provided by the power supply from the communication cables, then these cables must be connected to the BDH and BDL signal lines only.
Here is the source material that may have been referenced:
http://www.ia.omron.com/data_pdf/cat/cj1w-srm21_ds_e_2_2_csm1640.pdf?id=30
Technical Specifications
Part Number: CJ1W-SRM21 (CJ1WSRM21)Module Type: Control Module
CompoBus/S Master
Number of Input Output Points: 128 or 256
Weight: 1lbs (Approx.)
Related Parts
CJ1W-AD081-V1 - Omron CJ1 Input Control Module (CJ1WAD081V1)CJ1M-CPU13 - Omron CJ1 Control Module (CJ1MCPU13)
CJ1M-CPU21 - Omron CJ1 Control Module (CJ1MCPU21)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Omron CJ1 Shipping options vary by location. Call for an accurate quote.
Warranty
- The Omron CJ1W-SRM21 comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
