CJ1W-SCU21-V1


Part Number - CJ1W-SCU21-V1

Product PDF: pdf image

CJ1W-SCU21-V1 is

In Stock Ships Today!In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the CJ1W-SCU21-V1
5.0/5 on 2 reviews



Product Details

  • CJ1 Serial Communication Control Module (CJ1WSCU21V1)
  • Manufacturer: Omron
  • Series: CJ1

Product Description

The Omron CJ1W-SCU21-V1 (CJ1WSCU21V1) is a CJ1 series serial communication control module. The control modules current consumption is conditional based on the voltage rate. The control module has a voltage of 5V, the current consumption is 0.28 Amp, if the voltage is 24V, there will be no current consumption. The standards of the CJ1W-SCU21-V1 are the UC1, N, L, and CE.

The CJ1W-SCU21-V1 serial communication control module has two serial ports, both use the RS-232C interface. The RS-232C has various protocols such as communication methods, synchronization, baud rate, and connections. This interface corresponds with the EIA RS-232C. Above the ports of the CJ1W-SCU21-V1 is the unit number switch which determines what number the module is in the configuration. The CJ1W-SCU serial communication modules have 4 systems, the NJ, CJ, CP1H, and NSJ systems. The CJ1W-SCU21-V1 control module does not support the NJ system, but is able to support the other three systems, not including a NSJ controller from the NSJ system.

The CJ1W-SCU21-V1 control module can be joined to a Mitsubishi system configuration. This serial communication control module can be adjoined to a couple of other parallel units and a CPU module. The configuration in which the CJ1W-SCU21-V1 is a constituent of may be connected as a host link master to a CJ series serial communication controller configuration as mentioned in the penultimate paragraph. Through the ports of these modules, this configuration can connect to a temperature controller and a smart sensor. There are many other links that can be made by the EIA RS-232C adapter via the RS-232C interface.

Here is the source material that may have been referenced:
http://www.ia.omron.com/data_pdf/cat/cj1w-scu_ds_e_9_1_csm2151.pdf


Technical Specifications

Part Number: CJ1W-SCU21-V1 (CJ1WSCU21V1)
Module Type: Control Module
Serial Communication Ports
Weight: 0.24lbs (0.11kg)


Related Parts

CJ1M-CPU12 - Omron CJ1 Programmable Control Module (CJ1MCPU12)
CJ1M-CPU13 - Omron CJ1 Control Module (CJ1MCPU13)
CJ1M-CPU21 - Omron CJ1 Control Module (CJ1MCPU21)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CJ1 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron CJ1W-SCU21-V1 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
