CJ1W-OC211


Part Number - CJ1W-OC211

Product PDF: pdf image

CJ1W-OC211 is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the CJ1W-OC211
4.7/5 on 3 reviews



Product Details

  • CJ1 Output Control Module (CJ1WOC211)
  • Manufacturer: Omron
  • Series: CJ1

Product Description

The Omron CJ1W-OC211 (CJ1WOC211) is a CJ1 series output control module with 16 relay output points. This control module has a maximum switching capacity has a voltage of 250VAC and 24VDC while the current is 2 Amp, while CJ1W-OC211’s minimum switching capacity has a voltage of 5VDC and a current of 1mA. The current consumption differs in whether the voltage is 5V or 24V. At a voltage of 5V, the current will be 0.11 Amp and if the voltage is at 24V, the current is 0.096 as the maximum.

The CJ1W-OC211 output control module can participate in three disparate systems: the NJ, CJ, and the NSJ system. In each system, regardless of the status of the rack, being a CPU rack or expansion rack, the OC211 can be placed with 10 other modules.

The Omron CJ1W-OC211 output control module is able to connect with a motley of wires that can be either solid or stranded. The sizes of the water may be between the screw sizes of 0.08 to 1.5mm2. This control module has a spring-loaded clamps which can hitch to wires very securely, this makes it difficult for the wires to become loose from shocks or vibrations made by the CJ1W-OC211. This obliterates the necessity of re-tightening the screws that clamp on the wires during the conventional inspection. While this module is being tested, the spring clamps will be able to be contacted to inform the user the signal levels of the wiring.

Here is the source material that may have been referenced:
http://www.ia.omron.com/data_pdf/cat/cj1w-oc_oa_od_ds_e_8_7_csm1617.pdf


Technical Specifications

Part Number: CJ1W-OC211 (CJ1WOC211)
Module Type: Control Module
Number of Output points: 16
Weight: 0.37lbs (0.17kg)


Related Parts

CJ1M-CPU12 - Omron CJ1 Control Module (CJ1MCPU12)
CJ1M-CPU13 - Omron CJ1 Control Module (CJ1MCPU13)
CJ1M-CPU21 - Omron CJ1 Control Module (CJ1MCPU21)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CJ1 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron CJ1W-OC211 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
