CJ1M-CPU22
Product PDF:
CJ1M-CPU22 is
In Stock Ships Today!In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.com
Rate the CJ1M-CPU22
5.0/5 on 1 review
Product Details
- CJ1 Input Output Control Module (CJ1MCPU22)
- Manufacturer: Omron
- Series: CJ1
Product Description
The Omron CJ1M-CPU22 (CJ1MCPU22) is a CJ1 series input output control module. This control module has a capacity of 320 in and out points for every 10 units the CPU must manage. Its program capacity is 10,000 words and the data memory capacity is 32,000 words. Since there is no extended memory (EM), the data memory (DM) takes up all 32,000 words. The current consumption is 640mA when the voltage is at 5V. There are 20 built-in input or output points: 10 in, 6 out, 2 counter in, and 2 pulse out.The CJ1M-CPU22 input output control module has 32 cyclic tasks and 256 interrupt tasks, which if aggregated is 288 tasks. Every interrupt task can be used as an extra cyclic task, which means there can be up to 288 cyclic tasks. Cyclic tasks can use both the TKON(820) TKOF(821). There are four types of interrupt tasks and there are only a certain number which each type of task can use: 1 power OFF interrupt task, 2 scheduled interrupt tasks, 32 input and output interrupt tasks and 256 external interrupt tasks.
The Omron CJ1M-CPU22 control module has two input and output ports. The first port is the peripheral port links with various programming devices, even a programming console, or a host computer. If either the CS1W-CN118 or a CS1W-CN[]26 cable is used, this port may be permuted to a RS-232C port. The other port, the RS-232C port, can also connect to motley of programming devices other than a programming console, host computers, and numerous other mechanisms. The Omron CJ1M-CPU22 input output control module with the RS-232C port can use the NT link, 1:N, Host link, or peripheral bus protocols.
Here are the source material that may have been referenced:
http://www.ia.omron.com/data_pdf/cat/cj1m-cpu_ds_e_6_2_csm1610.pdf?id=1638
Technical Specifications
Part Number: CJ1M-CPU22 (CJ1MCPU22)Module Type: Input Output Control Module
Number of Input Output Points: 320
Weight: 1lb (approx.)
Related Parts
CJ1M-CPU12 - Omron CJ1 Programmable Control Module (CJ1MCPU12)CJ1M-CPU13 - Omron Control Module (CJ1MCPU13)
CJ1M-CPU21 - Omron Control Module (CJ1MCPU21)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Omron CJ1 Shipping options vary by location. Call for an accurate quote.
Warranty
- The Omron CJ1M-CPU22 comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
