CJ1G-CPU44H


Part Number - CJ1G-CPU44H

Product PDF: pdf image

CJ1G-CPU44H is

In Stock Ships Today!In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the CJ1G-CPU44H
5.0/5 on 1 review



Product Details

  • CJ1 Input Output Control Module (CJ1GCPU44H)
  • Manufacturer: Omron
  • Series: CJ1

Product Description

The Omron CJ1G-CPU44H (CJ1GCPU44H) is a CJ1 series input output control module with 1,280 points. The control module has a user program memory of 30,000 steps and a data memory (DM) of 32,000 words. The extended memory (EM) of 32K words times 1 bank. There are also many different types of flash memories, such as FB program memory, comment files, program index files, and symbol tables if the CJ1G-CPU44H is a version 3. The loop-control CPU has 1,280 input or output points and a current consumption of 0.91 Amp with the voltage of 5VDC.

The external features of the CJ1G-CPU44H control module include two ports and memory card connectors. The two ports of this module are the peripheral and the RS-232C port. The peripheral connects to programming devices and even host computers. The serial port connects to host computers, but also programming consoles. A memory card can also be connected to the CJ1G-CPU44H by its specific connector. There is a power switch for the memory card which disconnects the power so that one can safely dislocate the card. The indicators on the module are lit green or orange, green denotes power being supplied to the card and orange signifies that the card is being accessed.

The Omron configuration which the CJ1G-CPU44H module can be attached to a power supply and another specialized input output control module. They may be concatenated to these modules by connectors integrated in the side of the control module. Once connected to the acceptable units with connectors, it may be secured by sliders which are on the top of the control module.

Here is the source material referenced:
https://datasheet.octopart.com/CJ1GCPU42H-Omron-datasheet-11549389.pdf
http://www.omonr.com/pdfread/web/viewer.asp?ProductName=OMRON%20CJ1G-CPU44H%20INSTRUCTIONS%20REFERENCE%20MANUAL&brandid=1&Downloadid=10281
https://assets.omron.eu/downloads/manual/en/v1/w393_cj1m_g_h_cpu_units_operation_manual_en.pdf


Technical Specifications

Part Number: CJ1G-CPU44H (CJ1GCPU44H)
Module Type: Control Module
Number of Input Output Points: 1,280
Weight: 1lb (approx.)


Related Parts

CJ1G-CPU44P - Omron CJ1 Control Module (CJ1GCPU44P)
CJ1M-CPU13 - Omron CJ1 Control Module (CJ1MCPU13)
CJ1M-CPU21 - Omron CJ1 Control Module (CJ1MCPU21)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CJ1 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron CJ1G-CPU44H comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
