C200H-DA004


Part Number - C200H-DA004

C200H-DA004 is

In Stock Ships Today!In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the C200H-DA004
4.8/5 on 6 reviews



Product Details

  • C200H Output Control Module (C200HDA004)
  • Manufacturer: Omron
  • Series: C200H

Product Description

The Omron C200H-DA004 (C200HDA004) is a C200H series output control module with analog points. The control module signal range is from 4 to 20mA, and a load resistance of 600 ohms as the maximum. The C200H-DA004 control module has a power consumption current which is dependent on the voltage. If the voltage is at 5VDC, the current is 100mA; if the voltage is 26VDC, the current will be 250 max.

The C200H-DA004 control module has a terminal block that is attached to the module by the bolting of the block to the mounting screw (black M3). The control module has a terminal block with 28 screw (M3) terminals (named B0-B13 and A0-A13). which is all for current output. With its 28 terminals there are eight output points. Each output point is contrived of a current (-) output and a current (+) output. Nevertheless, terminals B0, B3, B6, B9, B12-13, A0, A3, A6, A9, and A12-13 have no connections.

The dimensions of the C200H-DA004 control module 34.5mm by 130mm by 128mm (1.36in by 5.12in by 5.04in if measuring width by height by depth). The weight of control module is 0.99lbs (0.45kg). In the Omron configuration, the C200H-DA004 is placed with many other specialized input output control modules, and it can be positioned in a configuration with up to 16 different units depending on CPU that manages the configuration. CPU’s that are apropos for the C200H-DA004 may be from the C200H, C200HS, or the C200HE/HX/HG series.

Here is the source material that may have been referenced:
https://www.lakewoodautomation.com/support/manuals/Omron/W325E104%20C200H-AD003%20DA003%20DA004%20MAD01%20Operation%20Manual.pdf


Technical Specifications

Part Number: C200H-DA004 (C200HDA004)
Module Type: Control Module
Number of Analog Output Points: 8
Weight: 0.99lbs (0.45kg)
