C200H-DA002
Product PDF:
C200H-DA002 is
In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.com
Rate the C200H-DA002
4.5/5 on 2 reviews
Product Details
- C200H Output Control Module DA 002 (C200HDA002)
- Manufacturer: Omron
- Series: C200H
Product Description
The Omron C200H-DA002 (C200HDA002) is a C200H control module with output points. This control module is suitably placed alongside its complementary analog input module the C200H-AD002. It is also coupled with multifarious specialized input output control modules and for some configurations, most especially with the C200H-CT001-V1 high-speed counter module. The CPU deployed for this configuration in which the C200H-DA002 is a member must be from either the C200H or the C200HS series.The C200H-DA002 has and external output terminal block connectors (which is removable). There are nineteen screw terminals denominated A0-A8 and B0-B9. There are four output points, but three of the terminals are not used: B8-B9 and A8. The A0-B0, A2-B2, A4-B4, and A6-B6 terminals are employed to disburse the voltage output. The voltage output signal range orbits between -10 and 10V. Terminals A1-B1, A3-B3, A5-B5, and A7-B7 are used for the C200H-DA002’s current output. The current output signal range spans between 4 to 20mA. The outputs are derived from the photocoupler which receives feed from the CPU and Bus interface, the photocoupler then relinquishes the output to the D/A converter, lastly releasing it from the output terminals.
The specifications of the C200H-DA002 output control module are as follows. The power consumption is 600mA when the voltage is 5VDC. The output current is 10mA. The maximum load resistance for the current output it 350 ohms and the output impedance maximum for the voltage output is 0.5 ohms. Lastly, the conversion time of the C200H-DA002 is 2.5ms for every point.
Here are the source material that may have been referenced:
https://www.lakewoodautomation.com/support/manuals/Omron/W229E13%20C200H-AD002%20C200H-DA002%20Operation%20Manual.pdf
Technical Specifications
Part Number: C200H-DA002 (C200HDA002)Module Type: Control Module
Number of Analog Output Points: 4
Weight: 0.71lbs (0.32kg)
Related Parts
C200H-CN422 - Omron C200H CableCJ1M-CPU13 - Omron CJ1 Control Module (CJ1MCPU13)
CJ1M-CPU21 - Omron CJ1 Control Module (CJ1MCPU21)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Omron C200H Shipping options vary by location. Call for an accurate quote.
Warranty
- The Omron C200H-DA002 comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
