C200H-DA001


Part Number - C200H-DA001

Product PDF: pdf image

C200H-DA001 is

In Stock Ships Today!In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the C200H-DA001
5.0/5 on 4 reviews



Product Details

  • C200H Output Control Module (C200HDA001)
  • Manufacturer: Omron
  • Series: C200H

Product Description

The Omron C200H-DA001 (C200HDA001) is a C200H series output control module with 2 points. This control module bestows an interface for many analog mechanism that can intake its voltage and current range. The C200H-DA001 control module has external output terminal block connectors. There are 19 screw terminals, 2 in which no wire can be hooked to, 4 terminals participate in voltage output, four participate in current output, 2 assist in pulse output, 2 outputs generate no voltage, and the last five generate voltage within the range of 5 to 24VDC. Above that there is the C200H-DA001 control module has a display screen in which the unit number setting switch is placed. This control module has 2 output points. Within the display screen, an when the indicator light is green defines a proper operation while a red light signifies that the control modules output has exceeded its upper or lower demarcations.

Some other specifications of the C200H-DA001 control module is its signal range, which has a voltage of 1-5V or 0-10V and a current of 4-20mA; the voltage resolution is 12-bits and likewise the current resolution id 12-bits.

The C200H-DA001 is able to be placed in the classic Omron configuration beside an Omron control module. In congruity with other Omron configuration, the analog input can also be fitted with other special input output control modules such as an analog input module, high-speed counter control modules, and the ASCII/BASIC module. This configuration would be able to connect to a servo amplifier and servo motor by various connections by cables.

Here are the source material that may have been referenced:
https://www.lakewoodautomation.com/support/manuals/Omron/W127E14%20C200H-AD001%20DA001%20Operation%20Guide.pdf


Technical Specifications

Part Number: C200H-DA001 (C200HDA001)
Module Type: Output Control Module
Number of Analog Outputs Points: 2
Weight: 1lb (Approx.)


Related Parts

C200H-B7A01 - Omron Interface 16 Output Points (C200HB7A01)
C200H-BC051 - Omron Backplane 5 Slots (C200HBC051)
C200H-CPU02 - Omron Control Module (C200HCPU02)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron C200H Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron C200H-DA001 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
