C200H-CPU21


Part Number - C200H-CPU21

Product PDF: pdf image

C200H-CPU21 is


Available


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the C200H-CPU21
5.0/5 on 8 reviews


Product Details

  • C200H Output Control Module 200V (C200HCPU21)
  • Manufacturer: Omron
  • Series: C200H

Product Description

The Omron C200H-CPU21 (C200HCPU21) is a 200V C200H series output control module with a current of 4.6 Amp. The control module has a voltage of 100-120VAC or 200-240VAC with a complimentary frequency 50/60Hz. The extended range may be able to operate at 85-132VAC or 170-264VAC. The output control module has a power consumption of 120V Amp and current of 30 Amp. The fuse has a current of 2 Amp and a voltage of 250V.

There are two racks that the C200H-CPU21 output control module may be placed on the expansion rack and the CPU rack. On the CPU rack the control module is also a power supply, only input output modules may be placed on it. With the expansion rack, both power supplies and I/O units may be placed on it.

The external features of the C200H-CPU21 output control module are these. There are five indicators on the control module on these will light up differently. The POWER and RUN indicators will light up green; the ALARM indicator may flicker red; and the ERROR and OUT INHIBIT will light up red. There is also a power fuse on the right, the C200H-CPU21 control module there is a terminal block which may be removed. Then there are four connectors, one is specifically for the applicable memory module. There are three other ports that attach with a programming console. Of these ports, one is utilized for storage, another for a classic connection, and the last one for handheld ones.

Here are the source material that may have been referenced:
https://www.mouser.com/datasheet/2/307/M11W111E1100406-16913.pdf
https://www.limasoft.cz/omron/pdf/c200h_hs.pdf


Technical Specifications

Part Number: C200H-CPU21 (C200HCPU21)
Module Type: Control Module
Voltage/Frequency: 100-120 or 200-240VAC, 50/60Hz
Weight: 13.27lbs (6.0kg)


Related Parts

C200H-CPU01 - Omron C200H Control Module (C200HCPU01)
CJ1M-CPU12 - Omron CJ1 Programmable Control Module (CJ1MCPU12)
CQM1-OC222 - CQM1 Output Control Module (CQM1OC222)
R88D-WT15H - Omron R88D Servo Drive (R88DWT15H)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron C200H Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron C200H-CPU21 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.


Additional Information

TRW Electric & Supply Company is a global automation supplier. We deliver reliable new and refurbished parts at a great value. Our product focus is Omron and Mitsubishi products, but we have been able to provide our customers with solutions from other manufacturers as well. Our goal is to supply the automation industry with the best service and pricing, and of course conduct business with a high level of integrity.






Authorized Distributors

A Omron Authorized Distributor for C200H is not the only source for Omron products. Many of the Omron products have been discontinued and therefore are no longer available from authorized suppliers. TRW Electric & Supply has many new and refurbished Omron C200H parts available for purchase.


More Information: C200H-CPU 21, C200H-CPU2, C 200H-CPU, C200 HCPU 21
