C200H-CPU03
C200H-CPU03 is
Available
Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.comProduct Details
- C200H Control Module with Power Supply (C200HCPU03)
- Manufacturer: Omron
- Series: C200H
Product Description
The Omron C200H-CPU03 (C200HCPU03) is a C200H series control module with a power supply. The control module has a voltage normally at 24VDC, but its range is 20.4 to 26.4VDC. The power consumption of the C200H-CPU03 control module is 40W and that is the general rate for each backplane or expansion or CPU rack. The fuse of the control module has a current 2 Amp and a voltage of 250VAC.The C200H-CPU03 control module with a power supply may connect with many different modules by utilizing the backplane. The disparate racks can hold different modules. With the CPU rack, many input output modules may be added, NO power supply is necessary because there is already a power supply built in. The C200H-CPU03 control module can connect to an expansion rack, but it cannot be placed on it. The expansion rack may hold both the input output modules and a power supply.
All the exterior features of the C200H-CPU03 control module with power supply will be adumbrated below. The control module has a terminal block that may be removed this terminal block has ten screws. Then there are a total of four connectors: the memory pack and three programming consoles. One console is for the ordinary type another for the handheld and the last one is used for storage. The C200H-CPU03 control module has a power fuse that which is positioned next to the terminal block. This control module has five indicators, two of them light up red with an ERROR and OUT INHIBIT, two of them light up green, the RUN and POWER with the ALARM one flashing red.
Here are the source material that may have been referenced:
https://www.mouser.com/datasheet/2/307/M11W111E1100406-16913.pdf
https://www.limasoft.cz/omron/pdf/c200h_hs.pdf
Technical Specifications
Part Number: C200H-CPU03 (C200HCPU03)Module Type: Control Module
Built in Power Supply
Voltage/Frequency: 24VDC
Weight: 13.27lbs (6.0kg)
Related Parts
CJ1M-CPU12 - Omron CJ1 Programmable Control Module (CJ1MCPU12)CJ1M-CPU13 - Omron CJ1 Control Module (CJ1MCPU13)
R88D-WT15H - Omron R88D Servo Drive (R88DWT15H)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Omron C200H Shipping options vary by location. Call for an accurate quote.
Warranty
- The Omron C200H-CPU03 comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
