C200H-CPU01-E


Part Number - C200H-CPU01-E

Product PDF: pdf image

C200H-CPU01-E is


Available


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the C200H-CPU01-E
4.8/5 on 6 reviews


Product Details

  • C200H Control Module CPU 01E (C200HCPU01E)
  • Manufacturer: Omron
  • Series: C200H

Product Description

The Omron C200H-CPU01-E (C200HCPU01-E) is a C200H series control module. The voltage of the control module ranges between 100-120VAC or 200-240VAC has a frequency of 50/60Hz. The standard range may be extended to 85-132VAC or 170-264VAC. Their power consumption is 120VA for each backplane or expansion or CPU rack. The C200H-CPU01-E control module has an output which has a current of 3A at a voltage of 5VDC for both CPU and expansion rack. Then, the power fuse for the control module has a voltage running at 5VDC while the current is at 2A.

The C200H-CPU01-E control module may be placed on a backplane. This control module can only be placed on the CPU rack, and not the expansion rack because it already has a power supply. On the CPU rack, only certain I/O modules may be placed.

These are the features that are of the C200H-CPU01-E control module. There is the power fuse, whose specifications have already been mentioned. Then there are the five indicators. Those indicators are the POWER, RUN, ALARM, OUT INHIBIT, and ERROR. The first to indicator are green lights, and the last two are red. The ALARM indicator will scintillate red. The C200H-CPU01-E control module also has a terminal block that has ten screws. There is also a connector that may link to a memory pack. The other three connectors unite with a programming console. One is for a handheld console, the below connector is for the standard consoles. The last connector may be used for storage.

Here are the source material that may have been referenced:
https://www.mouser.com/datasheet/2/307/M11W111E1100406-16913.pdf;
https://www.limasoft.cz/omron/pdf/c200h_hs.pdf


Technical Specifications

Part Number: C200H-CPU01-E (C200HCPU01-E)
Module Type: CPU Control Module
Voltage/Frequency: 100-120VAC or 200-240VAC, 50/60Hz
Weight: 13.27lbs (6.0kg)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron C200H Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron C200H-CPU01-E comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
