C200H-AD002
Product PDF:
C200H-AD002 is
In Stock Ships Today!In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.com
Rate the C200H-AD002
4.5/5 on 2 reviews
Product Details
- C200H Input Control Module (C200HAD002)
- Manufacturer: Omron
- Series: C200H
Product Description
The Omron C200H-AD002 (C200HAD002) is a input control module from the C200H series. The control module is placed next to its counterpart analog output module the C200H-DA002 with its basic configuration. Besides the C200H-AD002, there can be a horde of different specialized input output control modules. One control module that may be very salient for this analog input is the C200H-CT001-V1. The CPU control module used for this configuration may be either from the SYSMAC C200HS/C200H.There are indicator lights on the C200H-AD002 control module which denote the state of the module with either a green or red light. If the light is green, operation should be going on as usual. When the light is red, there is a disconnect in the wires; however, this light will only turn on if the input range is within 1 to 5 V/4 to 20mA. There is also a control module number switch that may be set between 0 and 9. Different settings will have contrasting IR and DM words. Lastly, there is a connector on the bottom of the C200H-AD002 that allows the control module to dispense inputs.
The C200H-AD002 input control module has multiple functions. One function is the ‘conversion prohibit setting’, which incapacitates the module from converting unexploited inputs from analog to digital; this commutes the processing time and can even mitigate the sampling time. There is also an ‘input range setting’ function that the C200H-AD002 control module has. This function can set the input range for every input number depending on the input signal used.
Here are the source material that may have been referenced:
https://www.lakewoodautomation.com/support/manuals/Omron/W229E13%20C200H-AD002%20C200H-DA002%20Operation%20Manual.pdf
Technical Specifications
Part Number: C200H-AD002 (C200HAD002)Module Type: Input Control Module
Analog Input Points
Weight: 1lbs (Approx.)
Related Parts
C200H-CPU21 - Omron C200H Output Control Module (C200HCPU21)CJ1M-CPU21 - Omron CJ1 Control Module (CJ1MCPU21)
R88D-WT15H - Omron R88D Servo Drive (R88DWT15H)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Omron C200H Shipping options vary by location. Call for an accurate quote.
Warranty
- The Omron C200H-AD002 comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
