MR-J4-60B
MR-J4-60B is
In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.comProduct Details
- Melservo MR-J4 Servo Amplifier 600W (MRJ460B)
- Manufacturer: Mitsubishi
- Series: MELSERVO MR-J4
Product Description
The Mitsubishi MR-J4-60B (MRJ460B) is a Melservo MR-J4 series servo amplifier that generates an output wattage of 600W. This servo amplifier has a main circuit power supply with a voltage of either a 3-phase or a 1-phase between 200 to 240VAC. Its frequency is 50/60Hz and its rated current 3.2A. The permissible voltage however, is likewise a 3 or 1 phase, but it ranges from 170-240VAC. The fluctuation of the frequency of the MR-J4-60B is ±5%. Regarding the output, the MR-J4-60B servo amplifier has a rated voltage of 3-phase at 170VAC and a rated current of 3.2A.There are many discrete motors that may suitably pair with the MR-J4-60B servo amplifier. Such motors are those of the rotary servo, linear servo, and direct drive motor families. The specific motors are the HG-SR51 (or 52), the HG-JR53, the LM-U2PBD-15M-1SS0, the TM-RFM006C20, and the TM-RFM006E20. These motors should be connected to the MR-J4-60B amplifier via using a servo motor power cable in the amplifiers junction terminal. The encoder cable is then also connected to the amplifier by affixing it to the CN2 port.
The MR-J4-60B servo amplifier has a peripheral connection that may be made by the many various ports scattered around the top of the amplifier. The two ports above the CN2 port, the CN1A and the CN1B, will connect to SSCNET III/H connectors for connections with servo system controllers that are consonant with the SSCNET III/H system. Above these ports is the CN5 port which permits USB connections so that the MR-J4-60B may connect to a personal computer.
Here is the manual referenced:
http://www.atronika.com/Mitsubishi/SERVO/MITSUBISHI_catalog_servo_j4.pdf
Technical Specifications
Part Number: MR-J4-60B (MRJ460B)Module Type: Servo Amplifier 600W
Voltage/Frequency: 200 to 240VAC, 3-phase or 1-phase 50/60Hz
Output Wattage: 600W
Weight: 2.2lbs (1.0kg)
Related Parts
F943GOT-LWD - Mitsubishi Operator InterfaceMR-J4-100B - Mitsubishi Melservo MR-J4 Servo Amplifier
HC-UFS73 - Mitsubishi Melservo HC Servo Motor (HCUFS73)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Mitsubishi MELSERVO MR-J4 Shipping options vary by location. Call for an accurate quote.
Warranty
- The Mitsubishi MR-J4-60B comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
