MR-J4-500B


Part Number - MR-J4-500B

MR-J4-500B is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the MR-J4-500B
3.5/5 on 2 reviews



Product Details

  • Melservo MR-J4 Servo Amplifier with SSC NETWORK (MRJ4500B)
  • Manufacturer: Mitsubishi
  • Series: MELSERVO MR-J4

Product Description

The MR-J4-500B (MRJ4500B) is a Melservo MR-J4 series servo amplifier with a SSC Network. The servo amplifier may be connected to 14 different motors. It may connect with eight different rotary servo motor, five linear motors, and one direct drive motor. The connection of these motor will be described in the last paragraph.

The MR-J4-500B servo amplifier with a SSC Network has a 3-phase voltage of 200 to 240VAC and 50/60Hz as its frequency. The voltage has a possible fluctuation between 170 to 264VAC and while similarly the frequency may fluctuate within ±5% and a rated current of 21.7A. With the MR-J4-500B has a 3-phase output voltage of 170VAC and the current is 28.0A. This permits the output wattage to be 5kW.

The MR-J4-500B servo amplifier may connect with many disparate peripheral equipment. The top of the amplifier has a CN5 port that connects with a USB (MR-J3USBCBL3M) cable to the personal computer. The two ports below the CN5 are the CN3 and the CN8 ports. The CN3 port connects to the input output signal connector which allows the amplifier to command forced stop input, braking, etc. While the CN8 port can connect with the STO input output signal connector (MR-D05UDL3M-B) to a MR J3-D05 safety logic unit or another safety relay unit. The MR-J4-500B servo amplifier can hitch to the CN2 port and a junction terminal block with a power cable for the servo motor and an encoder cable. The last two ports, the CN1A and CN1B, support the Servo System Control Network (SSCNET) III/H connection, allowing the MR-J4-500B to connect to various servo system controllers that happen to be compatible with the SSC NETWORK III/H system.

Here is the manual referenced:
http://www.atronika.com/Mitsubishi/SERVO/MITSUBISHI_catalog_servo_j4.pdf


Technical Specifications

Part Number: MR-J4-500B (MRJ4500B)
Module Type: Servo Amplifier
Servo System Control Network (SSCNET) SSC NETWORK
Voltage/Frequency: 200-240VAC, 3-phase 50/60Hz
Output Wattage: 5kW
Weight: 8.82lbs (4kg)


Related Parts

F943GOT-LWD - Mitsubishi Operator Interface
A0J2HCPU - Mitsubishi A Series CPUs A0J2 Controller
A4UCPU - Mitsubishi INPUT OUTPUT Controller



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO MR-J4 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi MR-J4-500B comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
