MR-J4-500A
MR-J4-500A is
In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.comProduct Details
- Melservo MR-J4 Servo Amplifier 5KW 200V (MRJ4500A)
- Manufacturer: Mitsubishi
- Series: MELSERVO MR-J4
Product Description
The Mitsubishi MR-J4-500A (MRJ4500A) is a 200V, 5kW Melservo MR-J4 servo amplifier. The servo amplifier has a rated output voltage is 170VAC with 3-phases and a rated output current of 28.0A. There are two input power supplies: main circuit and control circuit. The former is a 3-phase and the latter is a 1-phase. The main and control circuits have a 200 to 240VAC voltage and a frequency of 50/60Hz; though, nevertheless the voltage fluctuation is permitted to waver between 170 to 264VAC; the frequency can waver within -5% to 5%.The MR-J4-500A servo amplifier can connect to a terminal block by the CN1 port. The terminal block can connect to several disparate Mitsubishi control modules, specifically FX3, FX2, or Q series control modules. The CN2 port may connect the servo amplifier to the encoder of a certain servo motor that is scripted below. The CN3 port can attach to a touchscreen operation panel from the Mitsubishi GOT series. The MR-J4-500A servo amplifier may connect with a MR-J3USBCBL3M cable by the CN5 port; this connection permits the servo amplifier to link with a personal computer which utilizes a MR Configurator2. Then the CN8 port can connect to a MR-J3-D05 module. Connections might be made by a MR0D05UDL3M-B STO cable. Lastly, the CN6 port can connect to an analog monitor output.
The MR-J4-500A servo amplifier may connect to multiple different servo amplifiers: eight different rotary servo motors from the HG series; five discrete linear servo motors; and a single direct drive motor TM-RFM240J10.
Here is the manual referenced:
http://www.atronika.com/Mitsubishi/SERVO/MITSUBISHI_catalog_servo_j4.pdf
Technical Specifications
Part Number: MR-J4-500A (MRJ4500A)Module Type: Servo Amplifier
Voltage/Frequency: 200-240VAC, 3-phase 50/60Hz
Output Wattage: 5kW
Weight: 8.82lbs (4kg)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Mitsubishi MELSERVO MR-J4 Shipping options vary by location. Call for an accurate quote.
Warranty
- The Mitsubishi MR-J4-500A comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
