MR-J3-60B


Part Number - MR-J3-60B

MR-J3-60B is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the MR-J3-60B
Be the 1st to rate this product listing!



Product Details

  • Melservo MR-J3 Servo Amplifier 600W (MRJ360B)
  • Manufacturer: Mitsubishi
  • Series: MELSERVO MR-J3

Product Description

The Mitsubishi MR-J3-60B (MRJ360B) is a 600W Melservo MR-J3 series servo amplifier. The power supply of this servo amplifier has a frequency of 50/60Hz, which may be authorized to oscillate between -5% and +5% of the original frequency. The voltage of the power supply can run on either 1-phase or 3-phases. If it operates on 3-phases, then the voltage can span from 200 to 230VAC; yet, if the voltage functions on 1-phase, then the voltage is 230VAC. However the voltage is permitted to fluctuate at a greater range. For the 1-phase, the voltage may encompass 170 to 253VAC; while the 3-phase voltage can only range from 207 to 253VAC.

The MR-J3-60B servo amplifier may connect to only one servo motor that is the HF-SP52. This servo motor can attach by two different means. These means will be described below.

The MR-J3-60B servo amplifier has multiple ports and a few connectors. The CN2 port attaches to the encoder of the HF-SP52; the servo motor also connects to the servo amplifier’s CNP3 connector for its power supply. Then there are two ports which participate in the SSCNET III, the CN1A and CN1B, both ports attaches to other accompanying MR-J3-B servo amplifier; the CN1A connects to a CN1B port of the fellow servo amplifier and vice versa. The CN1A can also attach to a motion control module in the MELSEC Q series. The MR-J3-60B servo amplifier also concatenates to a personal computer that utilizes a MR Configurator by utilizing the CN5 ports. The remaining connectors, the CNP1 and CNP2, are employed for power supply, the main circuit for the CNP1 connector and the control circuit for the CNP2 connector.

Here is the manual referenced:
http://www.koningenhartman.nl/UserFiles/Product/Brochure/MELSERVO%20MR%20family%20Technical%20Catalogue.pdf


Technical Specifications

Part Number: MR-J3-60B (MRJ360B)
Module Type: Servo Amplifier
Voltage/Frequency: 200 to 230VAC, 3-phase 50/60Hz; 230VAC, 1-phase 50/60Hz
Output Wattage: 600W
Weight: 2.2lbs (1.0kg)


Related Parts

MR-J4-100B - Mitsubishi Melservo MR-J4 Servo Amplifier
HC-KFS43B - Mitsubishi Melservo HC Servo Motor with Brake (HCKFS43B)
HF-KP43B - Mitsubishi HF Series Servo Motor with Brake (HFKP43B)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO MR-J3 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi MR-J3-60B comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
