MR-J3-500B


Part Number - MR-J3-500B

MR-J3-500B is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the MR-J3-500B
Be the 1st to rate this product listing!



Product Details

  • Melservo MR-J3 Servo Amplifier (MRJ3500B)
  • Manufacturer: Mitsubishi
  • Series: MELSERVO MR-J3

Product Description

The Mitsubishi MR-J3-500B (MRJ3500B) is a 5kW, 200V Melservo MR-J3 servo amplifier. The power supply of this servo amplifier is functions on 3-phases, the voltage itself spans from 200 to 230VAC; yet, the voltage, while still running on 3-phase, is permitted to orbit the greater range of 170 to 253VAC. The frequency for the servo amplifier is 50/60Hz, but it is authorized to fluctuate between -5% and -5% of the 50/60Hz.

The MR-J3-500B servo amplifier may only connect to two disparate servo motors. These are the motors that may be appropriately linked to this specific servo amplifier: the HF-SP502 and HC-RP353.These may be linked to the servo amplifier by two connections.

There are multiple ports and connector integrated to the MR-J3-500B servo amplifier that can facilitate many connections. The first two ports, the CN1A and the CN1B, both link to the SSCNET III. With this linkage, the MR-J3-500B servo amplifier may attach to other like servo motors (MR-J3-B). The CN1A port may attach to the CN1B port of a servo amplifier that has come before this; the same may be done vice versa. The CN1A may also connect to a motion control module in a MELSEC Q series configuration. Beneath these ports is the CN2 port that attaches to a servo motor that has been designated. To make a power supply connection for the servo motor, a connection must be made with the MR-J3-500B servo amplifier’s ‘U, V, and W’ connector. The other two connectors of the servo amplifier are also utilized for the power supply.

Here is the manual referenced:
http://www.koningenhartman.nl/UserFiles/Product/Brochure/MELSERVO%20MR%20family%20Technical%20Catalogue.pdf


Technical Specifications

Part Number: MR-J3-500B (MRJ3500B)
Module Type: Servo Amplifier
Voltage/Frequency: 200 to 230VAC, 3-phase 50/60Hz
Output Wattage: 5kW
Weight: 10.14lbs (4.6kg)


Related Parts

MR-J2S-10B - Mitsubishi Melservo MR-J2 Servo Amplifier, SSC NETWORK (MRJ2S10B)
MR-J2S-10A1 - Mitsubishi Melservo MR-J2 Servo Amplifier (MRJ2S10A1)
HC-MFS053B - Mitsubishi Melservo HC Servo Motor with BRAKE (HCMFS053B)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO MR-J3 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi MR-J3-500B comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
