MR-J3-500A


Part Number - MR-J3-500A

MR-J3-500A is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the MR-J3-500A
Be the 1st to rate this product listing!



Product Details

  • Melservo MR-J3 Servo Amplifier 5KW 200V (MRJ3500A)
  • Manufacturer: Mitsubishi
  • Series: MELSERVO MR-J3

Product Description

The Mitsubishi MR-J3-500A (MRJ3500A) is a 5kW, 200V Melservo MR-J3 servo amplifier. This servo amplifier has a power supply that functions on 3-phases, the voltage it has spans from 200 to 230VAC. Nevertheless, the voltage is enabled to range between 170 to 253VAC. The frequency of the MR-J3-500A servo amplifier is 50/60Hz. This frequency is also permitted a greater variance of +5% to -5% of the already set 50/60Hz.

The MR-J3-500A servo amplifier can concatenate to two servo motors. The two motors which may be implemented to the servo amplifier are the: HF-SP502 and HC-RP353. How to connect the servo motor will be stated below.

The MR-J3-500A servo amplifier connects to the various modules and motors by its many ports. The CN5 port attaches to a PC (personal computer) by using the USB communication (the MR-J3USBCBL3M cord). This personal computer needs to be employing the MR Configurator software. The CN3 port attaches by a RS-232 communication which connects the MR-J3-500A servo amplifier to the GOT series operator touchscreen. Next, the CN1 port concatenates to a certain positioning control module (of either the FX series or Q series) and optionally to a terminal block. Below that port is the CN2 port that links to an encoder of the servo motor that has been selected. The other means of connection for the servo motor is connecting to the power supply of the MR-J3-500A servo amplifier which is the ‘U, V, and W’ connector. The last two connectors attach to power supplies, both main circuit and control circuit (running on either 3-phases or 1-phase).

Here is the manual referenced:
http://www.koningenhartman.nl/UserFiles/Product/Brochure/MELSERVO%20MR%20family%20Technical%20Catalogue.pdf


Technical Specifications

Part Number: MR-J3-500A (MRJ3500A)
Module Type: Servo Amplifier
Voltage/Frequency: 200 to 230VAC, 3-phase 50/60Hz
Output Wattage: 5kW
Weight: 10.14lbs (4.6kg)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO MR-J3 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi MR-J3-500A comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
