MR-J3-40A


Part Number - MR-J3-40A

MR-J3-40A is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the MR-J3-40A
Be the 1st to rate this product listing!



Product Details

  • Melservo MR-J3 Servo Amplifier (MRJ340A) 400W 200V
  • Manufacturer: Mitsubishi
  • Series: MELSERVO MR-J3

Product Description

The Mitsubishi MR-J3-40A (MRJ340A) is a 400W, 200V Melservo MR-J3 servo amplifier. The power supply operates on either 3-phases or 1-phase. If the voltage runs on 3-phases, the voltage itself will span from 200 to 230VAC but it is authorized to have a range of 170 to 253VAC; if, however, the voltage runs on 1-phase has a voltage of 230VAC but can sanctioned to span from 207 to 253VAC. The frequency of the MR-J3-40A servo amplifier is 50/60Hz. This frequency is allowed to waver between +5% to -5%.

There are only a couple of servo motors that are apposite to the MR-J3-40A servo amplifier. These suitable motors are these: the HF-KP43 and HF-MP43. The motors connect to two areas of the servo amplifier, as will be conveyed below.

The MR-J3-40A servo amplifier has many ports that can connect to various things. The CN3 port can attach to an operator display panel from the GOT series by using a RS-232 communication. Then the CN5 port connects to a personal computer with a USB communication, specifically using the MR-J3USBCBL3M cable. Then, the CN1 port connects to a positioning control (from the FX or Q series) module with an optional terminal block. The MR-J3-40A servo amplifier also has a CN2 port which connects to one of the appropriate servo motors. The other means by which the servo motor also attaches to is ‘U, V, and W’ connector. The other two connectors of the servo amplifier connect to the appropriate power supplies (either 3-phase or 1-phase).

Here is the manual referenced:
http://www.koningenhartman.nl/UserFiles/Product/Brochure/MELSERVO%20MR%20family%20Technical%20Catalogue.pdf


Technical Specifications

Part Number: MR-J3-40A (MRJ340A)
Module Type: Servo Amplifier
Voltage/Frequency: 200 to 230VAC, 3-phase 50/60Hz; 230VAC, 1-phase 50/60Hz
Output Wattage: 400W
Weight: 2.2lbs (1.0kg)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO MR-J3 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi MR-J3-40A comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
