MR-J3-100A


Part Number - MR-J3-100A

MR-J3-100A is

In Stock Ships Today!In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the MR-J3-100A
Be the 1st to rate this product listing!



Product Details

  • Melservo MR-J3 Servo Amplifier (MRJ3100A)
  • Manufacturer: Mitsubishi
  • Series: MELSERVO MR-J3

Product Description

The Mitsubishi MR-J3-100A (MRJ3100A) is a Melservo MR-J3 series servo amplifier that works a general purpose interface. The servo amplifier is compatible with certain motors from the following series: the HF-KP, the HF-MP, the HF-SP, the HC-LP, the HC-RP, the HC-UP, and the HA-LP. The MR-J3-100A servo amplifier has an output voltage of 170 V with an output frequency of 0-360Hz and an output current of 6.0 Amp.

The MR-J3-100A servo amplifier has a 3-phase input voltage of 200 to 230VAC and has a frequency of 50/60Hz, it does have a permissible voltage fluctuation spanning from 170 to 253VAC and a permissible frequency flux of ±5% It generates 1kW. The weight of the product itself is 3.1 pounds (1.4kg).

The MR-J3-100A servo amplifier has a display panel which exhibits data, alarms, and parameters. The motors of the motor series described above can link an encoder cable with a CN2 connector to the CN2 port and a motor power supply cable to the U, V, and W terminals. A RS-422 communications connects to the CN3 port and a GOT operator interface touchscreen. On the front side of the MR-J3-100A amplifier has an optional battery compartment for the MR-J3BAT battery. Also, there is a CN5 port for USB communication cable (MR-J3USBCBL3M) that can connect this servo amplifier to a personal computer. An optional junction terminal block, positioning controllers, and a control signal (which connects to programmable controllers) can be concatenated to the MR-J3-100A servo amplifier to its CN1 port.

Here is the manual referenced:
http://www.koningenhartman.nl/UserFiles/Product/Brochure/MELSERVO%20MR%20family%20Technical%20Catalogue.pdf


Technical Specifications

Part Number: MR-J3-100A (MRJ3100A)
Module Type: Servo Amplifier
Voltage/Frequency: 200 to 230VAC, 3-phase 50/60Hz
Output Wattage: 1kW
Weight: 3.1lb (1.4kg)


Related Parts

MR-J4-100B - Mitsubishi Melservo MR-J4 Servo Amplifier
MR-J4-70A - Mitsubishi Melservo MR-J4 Servo Amplifier
HC-KFS43 - Mitsubishi Melservo HC Servo Motor (HCKFS43)
HC-KFS43B - Mitsubishi Melservo HC Servo Motor with Brake (HCKFS43B)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO MR-J3 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi MR-J3-100A comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
