MR-J2S-700A
MR-J2S-700A is
In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.comProduct Details
- Melservo MR-J2 Servo Amplifier 200V (MRJ2S700A)
- Manufacturer: Mitsubishi
- Series: MELSERVO MR-J2
Product Description
The Mitsubishi MR-J2S-700A (MRJ2S700A) is a 7kW, 200V Melservo MR-J2 servo amplifier. There are two power supplies. The voltage of both power supplies is 200 to 230VAC and a frequency of 50/60Hz while the voltage can have an augmented range of 170 to 253VAC with the frequency increasing its oscillation between -5% and +5%. Nevertheless, the first power supply, the control circuit, runs on 1-phase while the main circuit runs on a 3-phase. Lastly, the control circuit also has a power consumption of 50W.The MR-J2S-700A servo amplifier may attach to four different servo motors: HC-SFS702(B), HA-LFS601(B), and HA-LFS702, HA-LFS701M(B). Servo motor connection is described below.
The MR-J2S-700A servo amplifier has six screw terminals. The top three screws can connect to a magnetic contactor, which itself than attaches to a circuit breaker. The other three screw terminals can connect to the servo motor which is then utilized. Then, there are four ports. Ports CN1A and CN1B ports may link to a terminal block; however, the CN1A port of the MR-J2S-700A servo amplifier may attach to a position control module, most especially to Mitsubishi modules from the Q series and FX2N series; while the CN1B port can connect to a control signal. Then, the CN2 port can be used to connect to one of the chosen servo motor’s encoder. Then, the CN3 port connects to a personal computer that deploys a MR Configurator to create a RS-232C. Above the ports, there is a battery compartment below the display panel. This battery compartment may contain the MR-BAT battery.
Here are the source material that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf;
http://www.andreoniautomazione.it/mr-j2-super-catalogue_gb.pdf
Technical Specifications
Part Number: MR-J2S-700A (MRJ2S700A)Module Type: Servo Amplifier
Voltage/Frequency: 200-230VAC, 50/60Hz, 3-phase
Output Wattage: 7kW
Weight: 15.9lbs (7.2kg)
Related Parts
MR-J2-70A - Mitsubishi Servo AmplifierMR-J2-70B - Mitsubishi Melservo Servo Amplifier
F943GOT-LWD - Mitsubishi Operator Interface
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Mitsubishi MELSERVO MR-J2 Shipping options vary by location. Call for an accurate quote.
Warranty
- The Mitsubishi MR-J2S-700A comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
