MR-J2S-500B


Part Number - MR-J2S-500B

MR-J2S-500B is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the MR-J2S-500B
4.7/5 on 3 reviews



Product Details

  • Melservo MR-J2 Servo Amplifier 5kW (MRJ2S500B)
  • Manufacturer: Mitsubishi
  • Series: MELSERVO MR-J2

Product Description

The Mitsubishi MR-J2S-500B (MRJ2S500B) is a Melservo MR-J2 series servo amplifier with an output wattage of 5kW. This servo amplifier has two power supplies producing 5kW. The first power supply is the control circuit which has a voltage of 200 to 230VAC with a frequency of 50/60Hz which runs on 1-phase. The voltage may even increase up to 170 to 253VAC. The second power supply is for the main circuit that is commensurable to the control circuit. The frequency may be permitted to fluctuate between +5% and -5%. The servo amplifier also has a control circuit power consumption of 50W.

There are many different servo motors that the MR-J2S-500B Melservo MR-J2 servo amplifier can connect several servo motors. The following servo motors are those which are appurtenant to this servo amplifier: HC-SFS502(B), HC-LFS302(B), HC-LFS702, HC-RFS353(B), HC-RFS503(B), HC-UFS352(B), and HC-UFS502(B).

The MR-J2S-500B MR-J2 servo amplifier has four ports and six screw terminal. The first of these ports is the CN1A port. This CN1A port connects to the motion control modules and positioning control modules. These control modules are either from the Mitsubishi A series or Q series. The next port connects to other similar servo amplifier or a terminal connector (MR-A-TM). Both the CN1A and the CN1B ports participate in the SSCNET system. Then CN2 port of the MR-J2S-500B servo amplifier may connect to the servo motor. Then, lastly the CN3 port can connect with a personal computer that utilizes the MR Configurator software to create a RS-232C communication. The display panel on the MR-J2S-500B servo amplifier has a battery compartment which may contain the MR-BAT battery and the axis setting area.

Here are the source material that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf
http://www.andreoniautomazione.it/mr-j2-super-catalogue_gb.pdf


Technical Specifications

Part Number: MR-J2S-500B (MRJ2S500B)
Module Type: Servo Amplifier
Voltage/Frequency: 200-230VAC, 50/60Hz, 3-phase
Output Wattage: 5kW
Weight: 10.8lbs (4.9kg)


Related Parts

MR-J2S-500A - Mitsubishi Melservo MR-J2 Servo Amplifier (MRJ2S500A)
HC-RFS353B - Mitsubishi Melservo HC Servo Motor with Brake (HCRFS353B)
HC-RFS503 - Mitsubishi Melservo HC Servo Motor, 5KW (HCRFS503)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO MR-J2 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi MR-J2S-500B comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
