MR-J2S-40A1


Part Number - MR-J2S-40A1

MR-J2S-40A1 is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the MR-J2S-40A1
5.0/5 on 2 reviews



Product Details

  • Melservo MR-J2 Servo Amplifier 100V (MRJ2S40A1)
  • Manufacturer: Mitsubishi
  • Series: MELSERVO MR-J2

Product Description

The Mitsubishi MR-J2S-40A1 (MRJ2S40A1) is a 100V servo amplifier from the Melservo MR-J2 series. There are four ports in the module which connect with various connectors. The CN1A connector hooks the servo amplifier to the positioning controllers, especially those in the FX2N family, the QD75P[] or QD75D[], and the A1SD75P1 (or P3). The CN1A connector appends the MR-J2S-40A1 to an operation panel’s I/O port. The CN2 connector links the port of the servo amplifier to its corresponding motor that is appropriate for the amplifier. The connector must be at the end of the encoder cable. The last port may connect with the CN3 connector to a PC by a RS-232C cable. The user may give commands and give entries to the servo amplifier.

The specifications of the MR-J2S-40A1 are as follows. The current consumption of the control circuit power supply is 50W. This power supply’s voltage 1-phase is 100 to 120VAC with a frequency of 50/60Hz. The main circuit power supply is also 1-phase with a voltage of 100 to 120VAC and a frequency of 50/60Hz. The fluctuation sanctioned for the MR-J2S-40A1’s voltage is between the 85 to 127VAC in 1-phase for both control circuit and main circuit power supply. The frequency is permitted to fluctuate between plus or minus 5%.

The climate of the MR-J2S-40A1 must remain within the suitable clime of 32 to 131oF (0 to 55oC) so that the operations of the amplifier may continue without any deleterious effects. Also, for the safety of the amplifier, no caustic or inflammable gasses, oil or dust should come in contact lest the amplifier be negatively affected.

Here are the manuals and brochures that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf
http://www.andreoniautomazione.it/mr-j2-super-catalogue_gb.pdf


Technical Specifications

Part Number: MR-J2S-40A1 (MRJ2S40A1)
Module Type: Servo Amplifier
Voltage/Frequency: 100-120VAC, 1-phase 50/60Hz
Output Wattage: 400W
Weight: 2.4lbs (1.1kg)


Related Parts

MR-J2S-40A - Mitsubishi Melservo MR-J2 Servo Amplifier (MRJ2S40A)
HC-KFS43K - Mitsubishi Melservo HC Servo Motor with KEY (HCKFS43BK)
HF-KP43 - Mitsubishi Servo Motor



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO MR-J2 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi MR-J2S-40A1 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
