HC-SF152K

HC-SF152K is

In Stock Ships Today!

Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com

Rate the HC-SF152K

4.0/5 on 1 review

Product Details

Melservo HC Servo Motor with a Key (HCSF152K)
Manufacturer: Mitsubishi
Series: MELSERVO HC

Product Description

The Mitsubishi HC-SF152K (HCSF152K) is a 1.5kW Melservo HC series servo motor with a key. The inertia moment is 20.0 J(x10^-4kg x m^2) or 109 WK^2(oz x in^2). The torque that is ordinarily rated at 7.16 (N x m) or 1015 (oz x in); but it may have a greater torque of 21.6 (N x m) or 3061 (oz x in). The current normally operates at 9.0A in the HC-SF152K servo motor but it may have a greater current of 27.0A. The speed is computed to be 2000rpm, but it may run at a speed of 3000rpm. The quickest speed allowable is 3450rpm, but this speed can only be held for a short time.

The HC-SF152K servo motor with a key is permitted to concatenate with only one servo amplifier, which is the MR-J2-200A. There are a few means in which the servo motor could link with the servo amplifier. One way is to link the encoder included in the servo motor with the encoder cable. This cable can then attach to the CN2 port belonging to the MR-J2-200A. The HC-SF152K servo motor must also link with a power supply, this is accomplished when there is an attachment to three of the screw terminals placed and incorporated on the top of the MR-J2-200A. The cable necessary is a power supply cable which concatenates to the three aforementioned screw terminals, the U, V, and W.

The HC-SF152K servo motor with key is of the medium inertia type, which is because its provenance is in the HC-SF series. It is also a medium capacity motor.

Here is the source material that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf;
http://www.andreoniautomazione.it/mr-j2-super-catalogue_gb.pdf

Technical Specifications

Part Number: HC-SF152K (HCSF152K)
Module Type: Servo Motor with a Key
Voltage: 122V
RPM: 2000rpm
Output Wattage: 1.5kW
Weight: Standard 19.8lbs (9kg)

Related Parts

HC-SF152 - Mitsubishi Melservo HC Servo Motor (HCSF152)
HC-SF152B - Mitsubishi Melservo HC Servo Motor with Brake (HCSF152B)
HC-SF152BK - Mitsubishi Melservo HC Servo Motor with Brake Key (HCSF152BK)

Shipping and Order Information

TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
Mitsubishi MELSERVO HC Shipping options vary by location. Call for an accurate quote.

Warranty

The Mitsubishi HC-SF152K comes with a two year warranty.
A three year warranty is available. Please inquire for pricing.
