HC-UFS43K


Part Number - HC-UFS43K

HC-UFS43K is


Available


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the HC-UFS43K
5.0/5 on 2 reviews


Product Details

  • Melservo HC Servo Motor with Key (HCUFS43K)
  • Manufacturer: Mitsubishi
  • Series: MELSERVO HC

Product Description

The Mitsubishi HC-UFS43K (HCUFS43K) is a Melservo HC series servo motor with key. This servo motor is a flat model with a small capacity motor. The HC-UFS43K servo motor is safeguarded by the IP65 enclosure protection. With the IP65 protection, the servo motor will be completely guarded against dust and from water dispense from a low pressure jet fired from any angle. The weight of this product is 3.75lbs (1.7kg).

The HC-UFS43K servo motor with key has an output wattage of 400W with the voltage at 119V. The rated torque (N x m [oz x in]) is 1.3 (184.1) as the continuous running duty of the motor. The maximum torque is 3.8 (538.1). Like other motors in the HC-[]FS series, the HC-UFS43K has a rated speed (rpm or r/min) is 3000rpm a maximum speed of 4500rpm. It can even reach the permissible instantaneous speed of 5175rpm. The power rate of this servo motor at a continuous rated torque (kW/s) is 47.7kW/s. The rated current is 2.8A with a maximum current of 9.24A.

The ambient temperature for the abode of the HC-UFS43K should remain, to keep the motors usual functions in normal operation, between the temperatures of "32 to 104°F (0 to 40°C)". In storage, the ambient temperatures should be between "5 to 158°F (-15 to 70°C)". The ambient humidity of the environs of the HC-UFS43K should not reach above the relative humidity of 80% while those in storage, the relative humidity should not be greater than 90%. The HC-UFS43K should be in a place that is not in direct sunlight. The atmosphere of the servo motor should be devoid of corrosive or inflammable gas, oil and dust mist.

Here is the source material that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf
https://www.enclosurecompany.com/ip-ratings-explained.php


Technical Specifications

Part Number: HC-UFS43K (HCUFS43K)
Module Type: Servo Motor with Key
Voltage: 119V
RPM: 3000
Output Wattage: 400W
Weight: 3.75lbs (1.7kg)


Related Parts

MR-J2-70A - Mitsubishi Servo Amplifier
HC-SFS81 - Mitsubishi Servo Motor (HCSFS81)
MR-J2-70C - Mitsubishi Melservo Servo Amplifier



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO HC Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi HC-UFS43K comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
