HC-UFS43B

HC-UFS43B is

Available

Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com

Rate the HC-UFS43B

5.0/5 on 1 review

Product Details

Melservo HC Servo Motor with a Brake (HCUFS43B)
Manufacturer: Mitsubishi
Series: MELSERVO HC

Product Description

The Mitsubishi HC-UFS43B (HCUFS43B) is a 400W servo motor with a brake from the Melservo HC series. The current operates usually at 2.8 Amp, but it can run at 9.24 Amp. The speed of the servo motor is 3000rpm (unlike some other of this series which are 2000rpm); it can run at a speed of 4500rpm, and it may even be able to momentarily operate at 5175rpm. The HC-UFS43B servo motor has a moment of inertia that is 0.447 J(x10^-4kg x m^2) or 2.444 J(oz x in^2). This is the case because this specific servo motor has a brake. Then the calculated torque is 1.3 (N x m) or 184.1 (oz x in); but the HC-UFS43B servo motor has an increased torque is 3.8 (N x m) or 538.1 (oz x in).

These four amplifiers, the MR-J2S-40CL, MR-J2S-40CP, MR-J2S-40B, and MR-J2S-40A may be applied to the HC-UFS43B servo motor. This how the connection can be made: first, this connection can be made by attaching the encoder which is in the servo motor to the chosen servo amplifier’s CN2 port. The cable that must be used is the encoder cable. A connection needs to be created between the servo motor and the power supply by connecting to the three screw terminals (U, V, and W) on the selected servo amplifier.

The HC-UFS43B servo motor is of the flat model motor type. This is owing to the fact it is from the HC-UFS series. It is also a servo motor with a medium capacity because it has an rpm of 3000rpm.

Here is the source material that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf

Technical Specifications

Part Number: HC-UFS43B (HCUFS43B)
Module Type: Servo Motor with a Brake
Voltage: 119V
RPM: 300rpm
Output Wattage: 400W
Weight: 5.29lbs (2.4kg)

Related Parts

HF-KP43B - Mitsubishi HF Series Servo Motor with a Brake (HFKP43B)
MR-J2S-100B4 - Melservo MR-J2 Servo Amplifier
HC-UFS72K - Mitsubishi Servo Motor with a Key (HCUFS72BK)

Shipping and Order Information

TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
Mitsubishi MELSERVO HC Shipping options vary by location. Call for an accurate quote.

Warranty

The Mitsubishi HC-UFS43B comes with a two year warranty.
A three year warranty is available. Please inquire for pricing.
