HC-SFS52K


Part Number - HC-SFS52K

HC-SFS52K is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the HC-SFS52K
5.0/5 on 1 review



Product Details

  • Melservo HC Servo Motor with Key (HCSFS52K)
  • Manufacturer: Mitsubishi
  • Series: MELSERVO HC

Product Description

The Mitsubishi HC-SFS52K (HCSFS52K) is a servo motor with a key from the Melservo HC-SFS series. The weight of this motor is 11lbs (5kg). The HC-SFS52K, as constituent of the HC-SFS series, is a medium inertia motor. Medium inertia motors has a stable control, effectuating performance from lower to higher speeds. With this capability, the HC-SFS52K can control a variety of applications. Certain applications that the servo motor can handle are turrets, X-Y tables, specialized machinery, and other related applications.

The HC-SFS52K servo motor may be linked to the MR-J2S-60A from the MR-J2S series. The protective structure of this servo motor is the IP65 protective enclosure, in which it is entirely closed in with no ventilation. The IP65 enclosure means the motor is entirely protected from dust contravention and water projected from low-pressure jets. The ambient temperature of the surroundings of the HC-SFS52K should be in between 32 and 104°F (0 to 40°C) and 5 and 158°F (-15 to 70°C) to maintain proper operations of the servo motor.

The HC-SFS52K’s specifications are as follows. Along with three other motors in the HC-SFS series, the HC-SFS52K as a rated speed (rpm or r/min) of 2000rpm, a maximum speed of 3000rpm and a top maximum permissible instantaneous speed of 3450rpm. The rated current that the servo motor has is 3.2A and a maximum current of 9.6A. The HC-SFS52K’s voltage is 126v and its voltage is 500W. The rated torque (N . m [oz . in]) of the servo motor’s continuous running duty is 2.39 and its maximum torque is 7.16.

Here is the source material that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf;
http://www.andreoniautomazione.it/mr-j2-super-catalogue_gb.pdf


Technical Specifications

Part Number: HC-SFS52K (HCSFS52K) Module Type: Servo Motor with Key
Voltage: 126V
RPM: 2000rpm
Output Wattage: 500W
Weight: 11lbs (5kg)


Related Parts

HC-PQ053 - Mitsubishi Melservo Servo Motor
MR-J2-70B - Mitsubishi Melservo Servo Amplifier
HC-SF202G2129 - Mitsubishi Melservo HC Servo Motor



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO HC Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi HC-SFS52K comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
