HC-SFS202B
HC-SFS202B is
In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.comProduct Details
- Melservo HC Servo Motor with Brake 2kW (HCSFS202B)
- Manufacturer: Mitsubishi
- Series: MELSERVO HC
Product Description
The Mitsubishi HC-SFS202B (HCSFS202B) is a 2kW Melservo HC servo motor with brake. The torque of the servo motor with a brake is usually 9.55 (N x m) or 1352.3 (oz x in). However, the torque is permitted to increase to 28.5 (N x m) or 4035.6 (oz x in). Its normal speed is 2000rpm; yet, however, the speed is permitted to increase to 2500rpm. Nevertheless, at least momentarily, it is still authorized for the servo motor with a brake to operate at speeds of 2875rpm. The HC-SFS202B servo motor with a brake also has a moment of inertia that is 52.5 J(x10^-4kg x m^2) or 287.0 J(oz x in^2), it is greater than normal because it has a brake. Lastly, the current is 11.0A in normal cases, but this may be increased to 33.0A.The HC-SFS202B servo motor with a brake has four applicable servo amplifiers, which are: the MR-J2S-200CL, MR-J2S-200A, MR-J2S-200B, and MR-J2S-200CP. These may connect with the servo motor with a brake as so. First, the encoder of the HC-SFS202B servo motor with a brake can attach to the CN2 port of the appointed servo amplifier by deploying an encoder cable. The other way of connection is attaching the servo motor with a cable, with a power supply cable, to the screw terminals (U, V, and W) on the top row of the servo amplifier. The purpose of this is for the HC-SFS202B servo motor with a brake to unite with power supply integrated in the servo amplifier.
Here is the source material that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf
http://www.andreoniautomazione.it/mr-j2-super-catalogue_gb.pdf
Technical Specifications
Part Number: HC-SFS202B (HCSFS202B)Module Type: Servo Motor with Brake
Voltage: 138V
RPM: 2000rpm
Output Wattage: 2kW
Weight: 39.7lbs (18kg)
Related Parts
MR-J2-70A - Mitsubishi Servo AmplifierHF-KP43B - Mitsubishi HF Series Servo Motor with Brake (HFKP43B)
HC-MFS73BK - Mitsubishi Melservo HC Servo Motor with Brake Key (HCMFS73BK)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Mitsubishi MELSERVO HC Shipping options vary by location. Call for an accurate quote.
Warranty
- The Mitsubishi HC-SFS202B comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
