HC-PQ23NK-UE
HC-PQ23NK-UE is
In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.comProduct Details
- Melservo HC Servo Motor with Key (HCPQ23NK-UE)
- Manufacturer: Mitsubishi
- Series: MELSERVO HC
Product Description
The Mitsubishi HC-PQ23NK-UE (HCPQ23NKUE) is a Melservo HC series servo motor with a key and NEMA, CE/UL, and whose voltage is 120V. This servo motor has a torque that is computed to be 90.7 (oz x in) or 6.5 (kgf x cm). The torque is permitted to be increased to 19.5 (kgf x cm) or 271.89 (oz x in). Then the HC-PQ23NK-UE servo motor also has a standard speed 3000rpm, but it is sanctioned to operate at an increased speed of 4500rpm. The fastest speed absolutely allowable is 5400rpm, but this can only be sustained provisionally. The ordinary current is 1.5A; nevertheless the HC-PQ23NK-UE servo motor can obtain a greater current of 6.0A. Then the moment of inertia is 0.487 WK^2(oz x in^2), 0.089 J(kg x cm^2), or 0.35 GD^2(kgf x cm^2). Finally, the power is normally rated to be 46.02kW/s while it has a maintained torque.There are only a few servo amplifiers that can be linked with the HC-PQ23NK-UE servo motor; they are the: MR-C20A1-L-UE, MR-C20A1-UE, MR-C20A-L-UE, and MR-C20A-UE. There are two connections that can be made by the servo motor by employing two cables. The encoder cables which may be used are the MR-JCCBL[]M-L with lengths of two, five, or ten meters. They can connect by uniting the appointed servo amplifier’s CN2 port with the encoder of the HC-PQ23NK-UE servo motor. The other connection can be made by a power cable which may then be used to link with the W terminal on any of those applicable servo motors.
Here is the source material referenced:
http://www.mitsubisih.com/pdfread/web/viewer.asp?ProductName=MITSUBISHI%20HC-PQ13B%20PDF%20datasheet&brandid=2&Downloadid=55675
http://www.maxymtechnologies.com/Maxym%20Support/Drive%20Motors/Melservo%20MR-C%20Manual.pdf
Technical Specifications
Part Number: HC-PQ23NK-UE (HCPQ23NKUE)Module Type: Servo Motor with Key
Voltage: 120V
NEMA, CE/UL
RPM: 3000rpm
Output Wattage: 200W
Weight: 2.12lbs (0.96kg)
Related Parts
HC-UFS72K - Mitsubishi Melservo HC Servo Motor with KEYHC-UFS72K - Mitsubishi Melservo HC Servo Motor with KEY (HCUFS72BK)
HC-UFS73 - Mitsubishi Melservo HC Servo Motor (HCUFS73)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Mitsubishi MELSERVO HC Shipping options vary by location. Call for an accurate quote.
Warranty
- The Mitsubishi HC-PQ23NK-UE comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
