HC-MFS43B


Part Number - HC-MFS43B

HC-MFS43B is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the HC-MFS43B
5.0/5 on 1 review



Product Details

  • Melservo HC Servo Motor with Brake (HCMFS43B) 400W
  • Manufacturer: Mitsubishi
  • Series: MELSERVO HC

Product Description

The Mitsubishi HC-MFS43B (HCMFS43B) is a 400W Melservo HC servo motor with a brake. The moment of inertia for the servo motor with brake is, since this specific motor has a brake, is 0.191 J(x10^-4kg x m^2) or 1.044 J(oz x in^2). The evaluated speed of the servo motor with a brake is 3000rpm; yet, the speed is allowed to be increased to 4500rpm, but even still, the speed authorized, even though temporary, is 5175rpm. The HC-MFS43B servo motor with a brake has a current that is in general, 2.8A, but because certain operations may cause it to exceed the computed current, the servo motor with a brake is therefore allowed to run at even 9.0A. Then, the torque is usually 1.3 (N x m) or 184.1 (oz x in); however, the authorized torque is 3.8 (N x m) or 538.1 (oz x in).

The four servo amplifiers: the MR-J2S-40B, MR-J2S-40CP, MR-J2S-40A, and MR-J2S-40CL, are all able to connect with the HC-MFS43B servo motor with a brake. Now there are two ways to attach these two products. One of the ways is simply connecting the encoder of the servo motor with a brake to the CN2 port of the delegated servo amplifier. This connection is completed by an encoder cable. Secondly, the HC-MFS43B servo motor with a brake may attach a to the servo amplifier top lay screw terminals: U, V, and W. The purpose of this connection is in order to link the power supply of the servo amplifier to the servo motor with a brake.

Here is the source material that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf;
http://www.andreoniautomazione.it/mr-j2-super-catalogue_gb.pdf


Technical Specifications

Part Number: HC-MFS43B (HCMFS43B)
Module Type: Servo Motor with Brake
Voltage: 122V
RPM: 3000
Output Wattage: 400W
Weight: 4.63lbs (2.1kg)


Related Parts

MR-J2-70A - Mitsubishi Servo Amplifier
HC-KFS43B - Mitsubishi Melservo HC Servo Motor with Brake (HCKFS43B)
MR-J2-70C - Mitsubishi Melservo Servo Amplifier



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO HC Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi HC-MFS43B comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
