HC-MFS23K
HC-MFS23K is
In Stock Ships Today!Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.comProduct Details
- Melservo HC Servo Motor with a Key (HCMFS23K)
- Manufacturer: Mitsubishi
- Series: MELSERVO HC
Product Description
The Mitsubishi HC-MFS23K (HCMFS23K) is a Melservo HC series servo motor with a key and an output wattage of 200W. This servo motor has a standard speed of 3000rpm but its speed may be authorized to be 4500rpm. The speed that the servo motor can increase to 5175rpm for a few moments. The HC-MFS23K servo motor with a key has a current of 1.5 Amp and the greatest allowable current is 5.0 Amp. The moment of inertia for the servo motor is 0.088 J(x10^-4kg x m^2) or 0.481 J(oz x in^2). The torque of the HC-MFS23K servo motor is normally 0.64 (N x m) or 90.6 (oz x in), but it might be allowed to reach the greatest torque of 1.9 (N x m) or 269.0 (oz x in).There are a few different servo amplifiers that the HC-MFS23K servo motor with key can attach with. They are the MR-J2S-20B, MR-J2S-20A, MR-J2S-20CP, or MR-J2S-20CL. These servo amplifiers are able to make certain connections with this servo motor with key in order to function well. The first way is to attach its encoder to the servo amplifier is a CN2 port by utilizing an encoder cable. The HC-MFS23K servo motor with key attaches itself by a cable to the power supply. This is accomplished by clamping three wires to the following screw terminals: the U, V, and W which these wires are members of the power cable.
Here is the source material that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf
http://www.andreoniautomazione.it/mr-j2-super-catalogue_gb.pdf
Technical Specifications
Part Number: HC-MFS23K (HCMFS23K)Module Type: Servo Motor with a Key
Voltage: 120V
RPM: 3000
Weight: 2.18lbs (0.99kg)
Related Parts
HC-KFS43B - Mitsubishi HC Servo Motor with Brake (HCKFS43B)MR-J4-100B - Mitsubishi Melservo MR-J4 Servo Amplifier
HC-MFS73BK - Mitsubishi Servo Motor with Brake and Key (HCMFS73BK)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Mitsubishi MELSERVO HC Shipping options vary by location. Call for an accurate quote.
Warranty
- The Mitsubishi HC-MFS23K comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
