HC-MFS23B

HC-MFS23B is

In Stock Ships Today!

Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com

Rate the HC-MFS23B

5.0/5 on 3 reviews

Product Details

Melservo HC Servo Motor with Brake (HCMFS23B)
Manufacturer: Mitsubishi
Series: MELSERVO HC

Product Description

The Mitsubishi HC-MFS23B (HCMFS23B) is a 200W Melservo HC series servo motor with a brake. The servo motor has a torque of 0.64 (N x m) or 90.6 (oz x in); however, the torque may be inflated to 1.9 (N x m) or 269.0 (oz x in). The current is normally 1.5 Amp but any operation can function (because it is authorized to) at 5.0 Amp. The normal speed of the HC-MFS23B servo motor is 3000rpm, but the greatest speed it may operate on is 4500rpm. Nevertheless, for a short time it may attain a speed of 5175rpm. The moment of inertia for the servo motor with a brake is 0.136 J(x10^-4kg x m^2) or 0.743 J(oz x in^2).

There are a four servo amplifiers, the MR-J2S-20A, MR-J2S-20B, MR-J2S-20CP, and MR-J2S-20CL, which may attach to the HC-MFS23B servo motor with a brake. Here is how it might connect with these servo amplifiers. Primarily, the encoder which belongs to the servo motor with a brake must attach, deploying an encoder cable, to the CN2 port of the chosen servo amplifier. In addition to this, the HC-MFS23B servo motor with a brake may also attach to three of the screw terminals of the chosen servo amplifier: U, V, W; by utilizing the power cable for the servo motor.

The HC-MFS23B servo motor with a brake is not only an ultra-low inertia motor, but it is also a small capacity motor. These types of motors can link to only two types of specific applications, which are named in this product’s manual.

Here is the source material that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf
http://www.andreoniautomazione.it/mr-j2-super-catalogue_gb.pdf

Technical Specifications

Part Number: HC-MFS23B (HCMFS23B)
Module Type: Servo Motor with Brake
Voltage: 120V
RPM: 3000
Output Wattage: 200W
Weight: 3.53lbs (1.6kg)

Related Parts

HC-UFS72K - Mitsubishi Melservo HC Servo Motor with KEY (HCUFS72BK)
HC-MF053 - Mitsubishi Melservo HC Servo Motor (HCMF053)
HC-MF053W1 - Mitsubishi Melservo HC Servo Motor (HCMF053W1)

Shipping and Order Information

TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
Mitsubishi MELSERVO HC Shipping options vary by location. Call for an accurate quote.

Warranty

The Mitsubishi HC-MFS23B comes with a two year warranty.
A three year warranty is available. Please inquire for pricing.
